OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
Specifications
Model Number :
N1241
Brand Name :
SMATiPC
Place of Origin :
Guangdong, China
MOQ :
1
Certification :
CE, FCC, ROHS
Price :
US $205-215
Payment Terms :
T/T
Delivery Time :
5-8 Work days
CPU Model :
Intel Processor N100 (Quad core quad threading, max turbo 3.4 GHz)
CPU Architecture :
Alder Lake-N
RAM Slot :
1*DDR4 3200MHz SODIMM Memory Slot, Max. 16GB
Storage Slots :
1*M.2 2280 slot, 1*2.5 inch HDD
Display Chip :
Intel(R) UHD Graphics
Display Ports :
1*HD, 1*DP
USB Ports :
3*USB2.0, 1*USB3.1
Network Ports :
4*Intel i225-V 2.5G LAN
Power Supply :
DC 12V
Work Temperature :
0℃~ +40℃ (HDD), -20℃~ +50℃ (SSD)
Work Humidity :
0% - 95% non-condensing
Dimensions :
144 * 136.7 * 42 mm
Net Weight :
0.79kg
Expansion Slots :
1*M.2 2280 M-key slot (SATA), 1*M.2 2230 E-key slot (WIFI/BT)
Throughput :
2.5GPS
Description

Notice: This link's price is barebone system price, doesn't include ram and hard disk, WiFi card and Wifi Antennas, if you need them, please contact us, we will give you the best price.

OEM Mini X86 PC 4x2.5Gb LAN Ports 4G 5G WiFi & N100 N150 Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
Product Paramenters
Model
Nano N1241
Color
Metal Gray (any color can be customized)
Material
High-quality all-aluminum alloy
CPU
Intel Processor N100 (Quad core quad threading, max turbo 3.4 GHz)
CPU Architecture
Alder Lake-N
BIOS
AMI EFI BIOS
RAM
1*DDR4 3200MHz SODIMM Memory Slot, Max. 16GB
Storage
1*M.2 2280 slot，1*2.5 inch HDD
Display Chip
Intel(R) UHD Graphics
Display Port
1*HD,1*DP
Front I/O
1*Power switch,1*DP,1*RJ45 COM(support Console function)
3*USB2.0, 1*USB3.1, 1*HD, 1*reset button
Rear I/O
4*RJ45 LAN, 1*DC IN, 1*SIM card slot
Network Card
4*Intel i225-V 2.5G LAN
Expansion
1*M.2 2280 M-key slot (support SATA protocol)
1*M.2 2230 E-key slot (support WIFI, BT)
Other Function
Power-on, timed power-on, network wake-up, PXE boot, watchdog (level 0-255), TPM2.0 security encryption
Power Supply
Support DC 12V
Work Temp
0℃~ +40℃, surface air flow (HDD), -20℃~ +50℃, surface air flow(SSD), surface air flow
Work Humidity
0% - 95% non-condensing
Cetificates
CE, CCC, FCC Class A, ROHS
Dimension
144 * 136.7 * 42 mm
Net Weight
0.79kg
Application
Firewall, VPN, network server, network security, router, ect
Details Images
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
Packing & Shipping
1.Delivery Time: 1 ~ 3 Days for one sample, 15 Working days for a large quantity.
2.Packaging Ways: Each pc for one neutral box;
3.Shipping Ways: For small amount, we advise our customer to take DHL, Fedex, UPS.
For a large quantity, we can support to ship by air or by sea.
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
Company Profile
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
IWILL TECHNOLOGY(HONGKONG) LIMITED. established in 2000, is an officially registered and approved large-scale resource-based enterprise, forcus on research and design,producing, processing, marketing and distribution. Main products cover Mini PC, Industrial PC,Firewall Appliance,Touch Panel PC,1U server and computer-related accessories.
IWILL TECHNOLOGY(HONGKONG) LIMITED. controls all the processes, from design, producing, processing, assembly, quality inspection to packing and delivering; and holds the advantage of leading technique and more competitive price.
IWILL TECHNOLOGY(HONGKONG) LIMITED. has established cooperation with lots of enterprises, rely on its strength, reasonable price,excellent service, over 10 years rich experience in R&D and producing. Products are popular at home and abroad. Its OEM/ODM services have already covered many countries in South East Asia, Middle East, Europe, America, South Africa etc.
Why Choose Us
1.Rich experience in R&D and Manufacturing and Exporting of more than 15 years, trustworthy.

2.3 years Warranty, the second year and the third year, we can repair it free. but we will charge for the parts that need to
change.

3.Owe CE, FCC, ROHS, ISO9001, CCC, TUV, and SGS Certification.

4.We can sell one sample for your test .

5.Support 7x24h customer services;

6.Seek long-term cooperation relationship
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
Certifications
OEM Mini PC with 4x2.5Gb LAN Ports N100 CPU Firewall Router Supports Pfsense & OPNsense Network Security
FAQ
Question: Can you put my brand name (logo) on these products?
Answer: Yes,.We can support OEM/ODM service, the process of customization is following:
1:provide your specific requirement. 2:our design engineer draw the design draft.
3:you confirm the design draft. 4.we start produce it.
Question: How much do I need to pay for your OEM servise?
Answer: You should pay extra 500$,but we will return the 500$ to you when your order over 100 pieces.

Question: What payment method do you accept?
Answer: T/T,Western Union,PayPal.

Question: What is the Minimum Order Quantity(MOQ)?
Answer: We can sell one piece sample for your test.

Question: What is the lead time of your products?
Answer: 1-3 days for one sample, 15 working days for a large quantity.
