2 Inch Flanged Water Meter Photoelectric Direct Reading Industrial Water Meter 1.6MPa
2 Inch Flanged Water Meter Photoelectric Direct Reading Industrial Water Meter 1.6MPa
Specifications
Brand Name :
HUIYUE
Model Number :
LXRY-50~300
Place of Origin :
China
Payment Terms :
T/T、D/P、D/A
Flow Range :
0.5-50 m³/h
Reading Method :
Direct Reading
Warranty :
1 year
Material :
Brass
Country Of Origin :
China
Connection Type :
Flange
Working Pressure :
1.6 MPa
Display :
Mechanical
Accuracy :
±1%
Size :
2 inches
Application :
Industrial/Commercial
Temperature Range :
0-50°C
Installation Type :
Horizontal
Packaging Details :
Individually packaged, carton packaged; size can be adjusted according to actual needs.
Delivery Time :
1~2weeks
Supply Ability :
5000pcs/month
Price :
$50~300usd.
Description

Introduction

This device is used to measure the cumulative flow and instantaneous flow of drinking water flowing through the tap water pipe,which made whit 304 stainless steel. It is suitable for large-scale meter monitoring systems and secondary metering systems such as enterprises and universities.

Product features

1. Long service life,suitable for ever type tubes.

2. Accurate reading: using infrared photoelectric direct reading technology, free from external interference.

2. Low power consumption: only connected to the power supply when collecting data, photoelectric passive direct reading code, the number is generated by the CPU and output through M-BUS or RS 485 BUS.

3. Unique structure: using dry detachable propeller mechanical structure, the counter is separated from the lower structure, and the reading remains clear permanently.

4. Easy maintenance: no need to disassemble from the pipeline, the replacement of the counter can be completed without stopping the water

Deployment conditions

1. Water temperature <50℃ (cold water meter)

2. Water temperature ≤90℃ (hot water meter)

3. Water pressure ≤1Mpa

4. The water meter cannot be immersed in water
