Bidirectional Metering WiFi Tuya Smart Circuit Breaker Adjustable Current 230V
Bidirectional Metering WiFi Tuya Smart Circuit Breaker Adjustable Current 230V
Bidirectional Metering WiFi Tuya Smart Circuit Breaker Adjustable Current 230V
Bidirectional Metering WiFi Tuya Smart Circuit Breaker Adjustable Current 230V
Bidirectional Metering WiFi Tuya Smart Circuit Breaker Adjustable Current 230V
Bidirectional Metering WiFi Tuya Smart Circuit Breaker Adjustable Current 230V
Bidirectional Metering WiFi Tuya Smart Circuit Breaker Adjustable Current 230V
Bidirectional Metering WiFi Tuya Smart Circuit Breaker Adjustable Current 230V
Specifications
Brand Name :
SIXWGH
Model Number :
WHDL
Certification :
CE,RoHS,FCC,UL
Place of Origin :
Shenzhen, China
MOQ :
500
Price :
USD+12-15+piece
Payment Terms :
D/A,L/C,T/T,D/P,Western Union
Supply Ability :
10000+piecex+10days
Delivery Time :
5-10days
Packaging Details :
9.1*2.1*7.3CM
Model Series :
1P-63A Smart Breaker
Rated Voltage :
AC 230V (80-300V Range)
Rated Frequency :
50/60Hz
Protection Functions :
Over-V, Under-V, Over-C
Reclosing Delay :
1s - 500s Adjustable
Metering Accuracy :
Class 1.0 (Active Energy)
Mechanical Life :
> 100,000 Times
Communication :
WiFi 2.4GHz + RS485 (Opt)
Installation :
35mm DIN Rail
Certificate :
CE, RoHS
Description

Core Specs - B2B Focus

Feature Specification
Rated Current 1-63A Adjustable
Metering Type Bi-directional (Solar/Grid)
Protection Over/Under Voltage & Current
Reclosing Automatic Self-Recovery
Prepaid Mode Balance Alert & Auto-Trip
Protocol WiFi 2.4GHz (Direct Connect)
Installation 35mm DIN Rail
Leakage Protection Optional (Adjustable)

Description - Business Pitch
Revolutionize property management with this Smart Circuit Breaker. Ideal for rental apartments and solar projects, it features Bi-directional Metering to track energy import/export. Landlords can use the Prepaid Function to automatically cut power when the tenant's balance runs out. It acts as a robust safety guard, instantly tripping during over-voltage or over-current events and automatically reclosing once safe, minimizing on-site maintenance costs.

Bidirectional Metering WiFi Tuya Smart Circuit Breaker Adjustable Current 230V

FAQ (Engineering & Management Focus)

  • Q: Can I use this for rental properties?

    • A: Yes, it is perfect for rentals. You can monitor electricity usage remotely and set it to turn off automatically if the tenant exceeds their prepaid energy limit.

  • Q: Does it support Solar PV systems?

    • A: Yes, it supports Photovoltaic Bidirectional Metering, measuring both the energy consumed from the grid and the energy generated by your solar panels.

  • Q: What happens if there is a voltage spike?

    • A: The breaker has adjustable Over/Under Voltage Protection. It will trip instantly to protect expensive appliances and will attempt to Auto-Reclose after a set delay when voltage stabilizes.

  • Q: Is the current limit adjustable?

    • A: Yes, you can adjust the current limit from 1A to 63A in the App to match the specific load requirements of the circuit.

  • Q: Can I control multiple breakers at once?

    • A: Yes, the Tuya App supports Group Control, allowing facility managers to turn off power for an entire floor or building with one tap.
