SLEEK 115 series minimalist narrow frame casement window with screen
SLEEK 115 series minimalist narrow frame casement window with screen
SLEEK 115 series minimalist narrow frame casement window with screen
SLEEK 115 series minimalist narrow frame casement window with screen
Specifications
Brand Name :
SLEEK
Model Number :
115 series
Certification :
NFRC
Place of Origin :
China
Material :
Aluminum
Opening Mode :
Manual
Specification :
Max. Width 900mm, Max. Height 1600mm
Glass Type :
Double / Triple Glazing Tempered Glass, Super White, Low E
Surface Treatment :
Paint, Powder Coating, Anodized
Color :
Standard And Customized Colors
Description
The SLEEK 115 series minimalist narrow frame casement window with screen redefines modern fenestration with its sleek, flexible handle design, delivering a contemporary aesthetic that elevates any architectural space. Paired with professional window railings, floor-to-ceiling configurations of this slim frame casement window offer a seamless blend of striking visual appeal and enhanced safety, making it a top choice for luxury residential and commercial projects.

As a premium aluminum casement window, it is engineered with robust anti-fall chain fittings and a single sash load capacity of 90kg, ensuring reliable performance and peace of mind. Special alloy die-cast corner brackets boost structural strength, while the 6060-T6 aluminum profile guarantees exceptional durability and stability. The generous 50mm glass groove accommodates a wide range of glass options, from energy-efficient double glazing to sound-dampening laminated glass, catering to diverse performance needs.

Co-extruded soft and hard rubber strips create superior weather sealing, reducing drafts and noise while improving energy efficiency—key benefits of this high-performance narrow frame casement window. The refined profile dimensions (outer frame 44.9mm, mullion 64.9mm, frame and sash 53.6mm) achieve a minimal 73mm visible overlap, maximizing the field of vision and flooding interiors with more natural light compared to traditional outward-opening windows.

Whether used in luxury villas, high-rise apartments, or modern commercial buildings, the SLEEK 115 series minimalist narrow frame casement window with screen combines smooth, effortless operation with timeless minimalist design, offering discerning homeowners and architects a perfect balance of safety, performance, and aesthetic elegance.
