Specifications
Model NO. :
PB2A16S20P
Battery Type :
LiFePO4/Li-ion/Lto
Balance Current :
2A
Charge/Discharge :
200A
Battery Strings :
8s-16s
Size/mm :
300*100*24mm
Package Weight :
1300g
Transport Package :
Carton Packaging
Specification :
1.1KG
Trademark :
JIKONG
Origin :
China
HS Code :
9032896085
Production Capacity :
500000 Pieces / Year
MOQ :
2 Pieces
Price :
US $73.86-89 / Piec
Description
PRODUCT MODEL
JK-PB2A16S20P
Number of Battery Strings(Li-ion)
7S-16S
Number of Battery Strings(Lifepo4)
8S-16S
Number of Battery Strings{LTO)
14S-16S
Balance Method
Active Balance(Full State On)
Balance Current
2A
Conductive Resistance in Main Circuit
0.35mΩ
Continuous Charge Current
200A
Continuous Discharge Current
200A
Maximum Discharge Current
400A
Over Charge Protection Current(ADJ)
10-200A
Other Interfaces(Defaut)
RS485/232/CAN
Proteetive plate size
300*100*24mm
Supply Voltage
20-70V
Standby power consumption
12mW
Operating temperature
-30-70°C
Maximum number ofcollection strings
16S
Wiring Output
Common Port
Display interface
Support
Heating interface
Support
Bluetooth Function
Support for Android/lOS/Harmony
Charging overwoltage, overeurrent protection
Support
Discharge uder woltage, over currentprotection
Support
Shont eireuit protection
Support
Battery parallel current limiting function
Support
Single Cell Voltage Range
1-5V
Voltage Acquistion Accuracy
±3mV
Over Charge Protection Voltage
1.2-4.4V Adjustable
Over Charge Relese Voltage
1.2-4.4V Adjustable
Over Current Detect Delay
2~600S Adjustable
Over Discharge Protection Voltage
1.2-4.4V Adjustable
Over Discharge Relese Voltage
1.2-4.4V Adjustable
Quantity of Temperature Detection
4
Temp Protection
Yes
Short Circuit protection
Yes
Coulomb Counter
Yes
Parallel charging current limiting
10A
Address dial swith
4
DRY Contact
2
Size/mm
300*100*24mm
