Industrial Ultrasonic Rubber Molds Cleaning Equipment
Industrial Ultrasonic Rubber Molds Cleaning Equipment
Industrial Ultrasonic Rubber Molds Cleaning Equipment
Industrial Ultrasonic Rubber Molds Cleaning Equipment
Industrial Ultrasonic Rubber Molds Cleaning Equipment
Industrial Ultrasonic Rubber Molds Cleaning Equipment
Industrial Ultrasonic Rubber Molds Cleaning Equipment
Industrial Ultrasonic Rubber Molds Cleaning Equipment
Specifications
Certification :
CE, ["CE, CE, CE","CE, CE"]
MOQ :
1
Model NO. :
JTS series
Automation :
Semi-automatic
Capacity :
360liter
Transducer Heads :
72PCS
Ultrasonic Power :
3600W
Heating Power :
9kw
Timer :
0~30min Adjustable
Heater :
0~80c Adjustable
Ultrasonic Frequency :
28/40kHz
Tank Dimension :
1000*600*600(L*W*H)
Tank Material :
SUS304 / SUS316L
Surface Finishing :
Hard-Cr Plating Treatment (20+ microns)
Housing Material :
Stainless steel
Generator Power :
AC 220V / 240V, 1, 13AMP
Overall Dimension :
1320*780*820(L*W*H)
Description
Industrial Ultrasonic Rubber Molds Cleaning Equipment
Industrial ultrasonic rubber molds cleaning equipment designed for efficient cleaning of diesel parts, engine blocks, and components with heavy oil and grease buildup. This system saves time and reduces labor costs while delivering superior cleaning performance.
Industrial Ultrasonic Rubber Molds Cleaning Equipment
Key Advantages
  • Customizable tank size to meet specific requirements
  • Adjustable ultrasonic power for optimal cleaning
  • Equipped with wheels for easy mobility
  • Integrated drainage system for convenient fluid management
  • Noise-reducing lid for quieter operation
  • Comprehensive 1-year after-sales service
  • Optional filtration system available
JTS-1072 Specifications
Tank Working Dimension 1000×600×600 mm (L×W×H)
Tank Total Capacity 360L
Tank Material SUS304 / SUS316L Stainless Steel
In-Tank Surface Finishing Hard-Cr Plating Treatment (20+ microns)
Housing Material Stainless Steel
Ultrasonic Frequency 28kHz / 40kHz
Ultrasonic Transducers 72 units
Maximum Ultrasonic Output Power 1800W
Electronic Generator KG1800
Heater Power (Hot Plate) 9kW
Generator Power Requirement AC 220V / 240V, 1, 13AMP
Advanced Features
  • Adjustable ultrasonic power control
  • Original BLT type transducers
  • SUS 304/316L stainless steel construction
  • Adaptable for continuous operation
  • Adjustable temperature controller
  • Separate control ultrasonic electronic generator
  • Sweep mode control capability
  • Digital timer and heating control
  • Optional boost mode and oil skimmer
  • Available pressure pump and filter system
Industrial Ultrasonic Rubber Molds Cleaning Equipment
System Functions
The JTS series single tank ultrasonic cleaner system features replaceable transducer boxes and generators that can be built-in or separate. Transducer placement is optimized for maximum cleaning efficiency in any parts cleaning application. Custom tank dimensions and transducer configurations are available to ensure perfect cleaning efficiency for both molds and parts. Optional stainless steel baskets are available.
Complete Model Specifications
Model: Skymen™ JTS-1012 JTS-1018 JTS-1024 JTS-1030 JTS-1036 JTS-1072
TANK'S WORKING DIMENSION (mm) L1 355 406 500 500 500 1110
W1 305 305 355 406 460 600
H1 355 460 500 500 550 600
OVERALL DIMENSION (mm) L2 535 586 680 710 710 1320
W2 485 485 535 586 640 780
H2 750 680 720 720 770 820
TANK'S TOTAL CAPACITY 38L 56L 88L 101L 126L 369L
ULTRASONIC TRANSDUCER 12 18 24 30 36 72
ULTRASONIC OUTPUT POWER (MAX.) 600W 900W 1200W 1500W 1800W 3600W
ELECTRONIC GENERATOR KG600 KG900 KG1200 KG1500 KG1800 KG3600
HEATER'S (HOT PLATE) POWER 1.5kW 3kW 4.5kW 9kW 9kW 9kW
Additional Frequency Options: 68kHz / 80kHz / 120kHz are also available upon request.
