Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Specifications
Place of Origin :
Shandong, China
Brand Name :
SAIKESAISI
Price :
$530.00/pieces 1-9 pieces
Production Rate :
0-300 ml/min
Weight :
1.5kg
Dimension(L*W*H) :
210mm 200mm 210mm
Warranty of core components :
1 year
Description
Product Description
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate

Product Introduction

QLC electrolysis cell is an advanced patented product, which are light , highly effective, energy-saving and of environmental protection , producing hydrogen and oxygen through the electrolysis of pure water (without adding alkali). That's PEM technology. The SPE electrodes, as the core of cell , are highly active catalytic electrode with nearly zero distance between the electrodes ,which is formed by integrating composite catalyst with and ion membrane with high electrolytic efficiency.

Working Principle

Electrolytic water meeting the requirements (with electrical resistivity >1MΩ/ cm) , after being put into the anode chamber of electrolytic cell, when power is switched on ,will be decomposed at once at the anode : 2H2O = 4H+ + 2O-2. The decomposed negative oxyanion (O-2) will immediately release electron to form oxygen (O2) gas.The hydrogen proton, in the form of aqua ion (H+.XH2 O),and under the action of electric field force, through SPE ion membrane, will arrive in the cathode to absorb electron to form hydrogen gas.
Specification
Brand Name
QLC-138A
Production Rate
0-300 ml/min
External Material
Aluminum alloy
Electrode material
titanium
Power supply requirement
DC 3-4V , 9A
Application Field
1.used for hydrogen&oxygen generator
2.used for Hydrogen Rich Water machine
3.used for health care equipment
4.used for experiment
Packing & Delivery
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
Compact and PEM Hydrogen Electrolyzer QLC-138A with 0-300 ml/min Production Rate
