10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal
10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal
10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal
10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal
10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal
10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal
10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal
10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal
Specifications
Focused spot diameter :
≤0.4mm
Tool bit focus :
F=100mm(optional)
Certification :
CE,FDA,ISO13485
Payment Terms :
T/T,Western Union
Working mode :
single pulse, continuous pulse, repeated pulse, ultra pulse
Delivery Time :
5~7 working days
Packaging Details :
Standard Flight Case Packaging
Key Word :
CO2 Fractional Laser Skin Tightening
Product Name :
Fractional CO2 Laser Machine
Price :
USD 3600~USD4500/unit
Aiming beam :
Red diode laser(650nm, 2mW)
Laser wavelength :
10.6μm
Model Number :
BR314
Place of Origin :
China
MOQ :
1
Output power :
0-60W(adjustable)
Brand Name :
Tuosite
Supply Ability :
1000 units/months
Description

10600NM Fractional CO2 Laser Machine Wrinkle Removal Scar Removal

Fractional CO2 Laser Machine Working Theory


The wavelength of frational CO2 laser machine is 10.6μm, which can be fully absorbed by human biology tissue (all the skin are available). The sealed-off Fractional CO2 laser machine, whose output laser-light will be transferred by articulated arm, which has better sense of direction and higher energy density.
The Fractional CO2 laser machine operates in the invisible infrared waveband, and an aiming beam is required to see where the treatment beam will impact tissue more recently from a visible red diode laser. When the laser beam go through the focus lens, the produced heat will gasify the target tissue.
With fractional laser resurfacing the laser beam is broken up or fractionated into many small micro beams which are separated so that when they strike the skin surface small areas of the skin between the beams are not hit by the laser and left intact. These small areas of untreated skin promote a much more rapid recovery and healing with less risk of complications. The small areas treated by the fractional micro beams, called micro treatment zones, cause sufficient laser injury to promote new collagen production and resultant facial skin rejuvenation.

Fractional CO2 Laser Machine Application


(1) Remove acne and acne marks;
(2) Eliminate dry pattern, fishtail, etc around the eyes;
(3) anti-aging: skin firming, wrinkle removal, improve the skin condition;
(4) Treatment of pigmentary lesions such as freckles and ostrum miracles;
(5) Scar: treatment of depressed, old dispersion, convex vascular / fibrous scar;
(6) Stretch marks.

Fractional CO2 Laser Machine Specification

Working mode single pulse, continuous pulse, repeated pulse, ultra pulse
Output power 0-60W(adjustable)
Input power 450VA
Laser type Sealed-off CO2 laser
Laser wavelength 10.6μm
Divergence angle 4mrad
Focused spot diameter ≤0.4mm
Tool bit focus F=100mm(optional)
Pulse width 0.02-0.99s
Aiming beam Red diode laser(650nm, 2mW)
Transmission system Spring-balanced 7 joint arms
Cooling system Inside-circle coolant
Display screen LCD
Working environment temperature 5-40ºC
Humidity <80%
Air pressure 86Kpa-106 Kpa
Input power AC220V±10%, 50Hz
Preheating-time >5min
Electromagnet No electromagnet interrupt
other working environment No obvious shaking or airflow
N. W. 37kgs
Size 183 (with arms) ×45×40cm

10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal

10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal

10600NM Fractional Co2 Laser Treatment Machine Wrinkle Removal Scar Removal
