10 Port Industrial Gigabit PoE Switch With 8 PoE+ Ports And 2 SFP Slots IP30
10 Port Industrial Gigabit PoE Switch With 8 PoE+ Ports And 2 SFP Slots IP30
10 Port Industrial Gigabit PoE Switch With 8 PoE+ Ports And 2 SFP Slots IP30
10 Port Industrial Gigabit PoE Switch With 8 PoE+ Ports And 2 SFP Slots IP30
10 Port Industrial Gigabit PoE Switch With 8 PoE+ Ports And 2 SFP Slots IP30
10 Port Industrial Gigabit PoE Switch With 8 PoE+ Ports And 2 SFP Slots IP30
Specifications
Brand Name :
Sirivision
Model Number :
SR-SHG3210FPI
Certification :
CE, ROHS, FCC, UKCA
Place of Origin :
Shenzhen，China
MOQ :
20
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50000pcs Per Month
Delivery Time :
5-8 work days
Packaging Details :
1pc in box, 1pc Warranty Card in box
Product Name :
8 10/100/ 1000Mbps RJ45 2 Gigabit SFP Industrial full Managed PoE Switch
Warranty :
replacement within 1 year; 3 years repairing
Mounting Method :
Din-rail and wall mounting
Safety Class :
IP30, EMC
Speed :
10/100/1000Mbps
Voltage :
44-57 VDC
Description

IP30 Protection, 10 Port Industrial Gigabit Poe Switch With 8 PoE+ Ports And 2 SFP Slots SR-SHG3210FPI

Industrial Easy Smart Gigabit PoE Switch With 2GE SFP Slots And 8GE RJ45 Ports

Description Of The Industrial Fiber Switch:

The SR-SHG3210FPI is a 10 port industrial fully managed PoE switch equipped with 8 Gigabit RJ45 ports and 2 Gigabit SFP slots. 8*10/100/1000Base-T RJ45 ports support POE power supply to meet the needs of PoE in various industrial fields.

Features Of The Industrial Switch Manufacturers:

  • Offers high-bandwidth connectivity with high-speed 8× Gigabit RJ45 ports and 2× Gigabit SFP slots.

  • Supports IEEE 802.3, 802.3i, 802.3u, 802.3x, 802.3z, 802.3ab, 802.3af, 802.3at.

  • 8 IEEE 802.3af/at PoE+ ports with a total output power of 150 W, and up to 30 W per port.

  • It can supply the PoE terminal equipment, such as wireless AP, network camera, network telephone, industrial sensor and so on, to meet the demand for high density PoE power supply network environment.

  • supports a variety of network redundancy protocol STP/RSTP/MSTP.

  • When one way network fails, communication can be recovered quickly to ensure uninterrupted communication of important applications.

Product Spectification Of The 8 Port Fiber Optic Sfp Poe Switch:

SR-SHG3210FPI

Power Supply

44~ 57 VDC/ 3A(MAX)

Standards

IEEE 802.3, 802.3i, 802.3u, 802.3x, 802.3z, 802.3ab, 802.3af,

802.3at

Ports

8×10/100/1000Mbps RJ45 ports+2×SFP ports

Indicators

Speed Indicators, Link/Act Indicators, SFP Indicators, PWR1,

PWR2, SYS

Ethernet Port Feature

10/100/1000BaseT (X) automatic detection, full / half duplex

MDI/MDI-X adaptive

SFP Port Characteristic

Gigabit SFP optical fiber interface, default matching optical

modules, need to buy separately, (optional order mode / multi-

mode, single fiber / double fiber optical module.

Forwarding Mode

Store and Forward(Full Wire Speed)

Dimensions

153 mm * 122 mm * 50 mm

PoE port

8 802.3at/af standard POE

Max / Average Power Port

30W per port

Power Consumption

Standby:<10W(NOT PoE);Full load:<150W(with PoE)

MAC Address Table

8K

Switching Capacity

20Gbps

Packet Forwarding Rate

14.88Mpps

Packet Buffer

4Mbit

Installation

DIN-rail/wall mount

Net /Gross Weight

<1.2kg / <1.5kg

Warranty

3 years , lifelong maintenance

Environment

Operating Temperature: -40℃ — 75℃ (-40℉~167℉)
Storage Temperature:-40℃ — 85℃ (-40℉ ~185℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Soft Features:

L3 Features IPV4/IPV6
Dynamic ARP
L2 Features Flow Control
802.3x (full duplex)
Back pressure (half duplex)
Link aggregation
Spanning Tree 802.1D (STP),802.1w (RSTP),802.1s (MSTP)
ERPS,BPDU Filtering
Self-loop detection
Automatic Edge Port
VLAN Port based VLAN(4k)
MAC address-based VLANs
protocol based VLAN
Voice VLAN
Monitoring VLANs
IEEE802.1q VLAN,QinQ (IEEE 802.1ad),GVRP
4096 static VLANs
multicast IGMP Snooping(v1,v2,v3)
Multicast VLAN, 1024 multicast groups
MLD Snooping V1/V2
Multicast VLAN Registration (MVR)
Industrial Ring Network ERPS Ring<20ms
QoS 8 priority queues per port
TOS, DSCP, 802.1p priority field rewrites
Queue Scheduling WRR,WFQ,WRR+SP, WFQ+SP
ACL L2/L3/L4, MAC-based, IP-based, port-based, VLAN-based
Security Features IEEE 802.1X certification
Storm Control
DHCP Snooping
Dynamic ARP Check
BPDU,SSH v1/v2
Management Supported CLI, Console, SNMP v1/v2/V3, Web, RMON management
Diagnosis mirror Many-to-One
UDLD,System Log (RFC3164)
System Diagnosis,Port Diagnostics,Network Diagnosis

Product Application Of The Industrial Managed Poe Switch:
