400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen
400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen
400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen
400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen
400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen
400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen
400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen
400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen
Specifications
Brand Name :
KUNYA
Model Number :
KYF-2101081
Place of Origin :
CHINA
MOQ :
1 SQM
Price :
USD$0.9-USD$55 per SQM
Payment Terms :
Western Union, T/T
Supply Ability :
16854200 SQM per month
Delivery Time :
15-25 days
Packaging Details :
wooden case
Product name :
Filter Wire Mesh
Application :
Filters
Weave style :
Plain weave, twill weave ,dutch weave
Wire diameter :
14#-50#
Mesh :
1-8000 Mesh
Material :
201,202,302,304,304L,316,316L
Technique :
Woven
Length :
30m per roll or as required
Width :
1.2m,1m,0.5-2m,can be customized
Usage :
chemical industry
Description

120 200 300 400 500 600 Micron 316 Stainless Steel Filter Wire Mesh

Filter Wire Mesh Introductions

● Plain,Twill Weave Wire Mesh

● Plain Weave Mesh: 1 mesh to 400 mesh

● Twill Weave Mesh: 400 mesh to 635 mesh Twill Duntch Weave Wire Mesh

● Twill Dutch Weave Mesh: 20x250mesh to 400X2800mesh

Stainless steel wire mesh cloth is made by stainless steel wire and then woven together to form a square opening or oblong opening. Due to its own characteristics of stainless steel, the stainless steel mesh processed has high wear resistance, long service life, accurate mesh, uniform structure, no curl, easy to use, uniform screen thickness, anti static, anti-acid and alkali resistance Corrosion.

Filter Wire Mesh Advantages

The product has the characteristics of acid and alkali resistance, temperature resistance, wear resistance and other properties, therefore, in recent years, stainless steel net is widely used in many different fields.

Filter Wire Mesh Specifications

Mesh Wire Diameter Mesh Wire Diameter Mesh Wire Diameter
3 1.0mm 24 0.19mm-0.5mm 90 0.1mm-0.12mm
4 0.7mm-1.5mm 26 0.19mm-0.4mm 100 0.07mm-0.14mm
5 0.6mm-1.2mm 28 0.19mm-0.35mm 110 0.08mm-0.09mm
6 0.5mm-1.0mm 30 0.15mm-0.4mm 120 0.07mm-0.1mm
7 0.5mm-0.8mm 32 0.17mm-0.3mm 140 0.06mm-0.07mm
8 0.4mm-1.0mm 34 0.23mm 150 0.06mm-0.07mm
10 0.3mm-1.0mm 35 0.25mm-0.3mm 160 0.06mm
12 0.3mm-0.8mm 36 0.15mm-0.28mm 180 0.05mm
14 0.27mm-0.7mm 40 0.12mm-0.27mm 200 0.05mm-0.06mm
16 0.25mm-0.7mm 50 0.13mm-0.25mm 300 0.03mm-0.04mm
18 0.20mm-0.55mm 60 0.1mm-0.19mm 400 0.023mm-0.03mm
20 0.19mm-0.55mm 70 0.1mm-0.15mm 500 0.025mm
22 0.21mm-0.5mm 80 0.08mm-0.17mm 635 0.018mm

400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen

400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen

400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen


400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen400X2800 20x250 Stainless Steel Wire Cloth Woven Metal Screen
