High Power Cooled BOSA with Pigtail Featuring Stable Single Longitudinal Mode Emission and Built-in Optical Isolator
High Power Cooled BOSA with Pigtail Featuring Stable Single Longitudinal Mode Emission and Built-in Optical Isolator
Specifications
Place of Origin :
China
Output Power :
2mW@30mA
Payment Terms :
T/T
Side Mode Suppresion Ratio :
35dB
Power Monitor Dark Current :
10nA
Tx Bandwith (-3dB) :
1.2GHz
Optical Isolation :
＞25dB
Thermistor Resistance@25℃ :
10kΩ
CTB(Ith+20mA) :
-60dBc
CSO(Ith+20mA) :
-55dBc
Slope Efficiency :
0.14W/A
Delivery Time :
5-8 work days
Linewidth :
2MHz
Relative Intensity Noise :
-145dB/Hz
Center Wavelength :
λ±5nm
Power Monitor Current :
100~1000uA
TEC Voltage :
＜1.2V
Brand Name :
LT
Threshold Current :
8mA
MOQ :
1
TEC Current :
0.5A
Description
Cooled BOSA with Pigtail
Key Features
  • High power
  • Stable single longitudinal mode emission
  • TEC and thermistor inside
  • High linearity PIN
  • Built-in Optical Isolator and WDM filter
  • Compact BOSA package
  • Compliant with GR-468
Applications
  • RFOG
  • CATV
