High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
Specifications
Production Capacity :
Customized
Weight (KG) :
888
Color :
Red/Yellow
Place of Origin :
Shandong, China
Voltage :
Customized
Core Components :
Consult customer service
Size3 :
17000 * 2400 * 2620(L x W x H)
Power(W) :
Customized
Size1 :
17,740 * 2,680 * 3,000(L x W x H)
Dimension(L*W*H) :
17740*2680*3000/15430*1500 *3400/17000*2400*2620
Model Number :
1 set
Size2 :
15430 * 1500 * 3400(L x W x H)
Brand Name :
Zhong Rui Wei Fei
Warranty :
1 Year
MOQ :
$150000-$250000
Application :
Marine equipment
Description
Product Paramenters
Size
17,740 × 2,680 × 3,000(L x W x H)
Adapted Drilling Rig Height (m)
9
2Maximum Tubing String Length (m)
13.7
Maximum Load Capacity (kN)
45
Maximum Tubing Diameter (")
Casing:20"; Drill Pipe:11"
Weight (t)
29
Size
15430 × 1500 × 3400(L x W x H)
Adapted Drilling Rig Height (m)
7
2Maximum Tubing String Length (m)
12
Maximum Load Capacity (kN)
9
Maximum Tubing Diameter (")
Casing:7"; Drill Pipe: 4-3/4"
Weight (t)
15.2
Size
17000 × 2400 × 2620(L x W x H)
Adapted Drilling Rig Height (m)
10.5
2Maximum Tubing String Length (m)
14.3
Maximum Load Capacity (kN)
45
Maximum Tubing Diameter (")
Casing: 24"; Drill Pipe:11"
Weight (t)
24
Products Description
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
Company Profile
High End Large Size Power Catwalk Heavy Duty Customizable Tubular Handling System
About us
Qingdao Zhongrui Weifei Marine Equipment Co., Ltd., founded in 2019 in Qingdao West Coast New Area, is a joint - venture of Ruiyuan Holdings Group and Kerui Group with a 300 - million - yuan registered capital. As a national high - tech entity, it masters the full value chain of marine oil and gas equipment, from R&D to after - sales service.
Specializing in high - end intelligent oil and gas equipment for marine and underwater use, its main products include automated drilling and repair gear, production - enhancing equipment, ship - based nitrogen producers, and underwater wellhead Christmas tree support. Guided by the quality policy of "Pursuing Excellence, etc." and business philosophy of "Integrity, etc.", it is making strides towards its goal of making marine oil and gas equipment safer and more intelligent.
