SINOTRUCK HOWO chinese dump 6x4 8x4 tipper 15tons 20ton sand transport sino truck trucks dump truck
SINOTRUCK HOWO chinese dump 6x4 8x4 tipper 15tons 20ton sand transport sino truck trucks dump truck
Specifications
Condition :
New
Steering :
Left
Horsepower :
251 - 350hp
Emission Standard :
Euro 2
Brand Name :
SINOTRUK
Place of Origin :
Hubei, China
Segement :
Medium-sized truck
Market Segement :
Highway transportatopn
Fuel Type :
Diesel
Engine Capacity :
> 8L
Transmission Type :
Manual
Forward Shift Number :
5
Maximum Torque(Nm) :
500-1000Nm
Dimensions (L x W x H) (mm) :
7700*2500*3400
Cargo Tank Dimension :
7700*2500*3400
Cargo Tank length :
≥8m
Gross Vehicle Weight :
9000
Capacity (Load) :
11 - 20T
Drive Wheel :
8X4
Passengers :
3
Rear Camera :
None
ABS(Antilock Braking System) :
Yes
ESC(Electronic Stability Control System) :
Yes
Touch Screen :
None
After-sales Service Provided :
Video technical support
Product name :
Dumper Truck
Color :
Customer's Request
Engine :
WD615.47
Tire :
Radial Tyre
Driving type :
LHD RHD
Transmission :
HW19710
Brand :
SINOTUK HOWO
Cab :
HW76
Loading capacity :
10 Tons
Type :
Dumping Truck
Packaging Details :
Nude Pack. The packing shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland.
Port :
shanghai and other
Supply Ability :
500 Unit/Units per Month
Price :
$20,000.00 - $30,000.00/Units
Description
Product Description
SINOTRUCK HOWO chinese dump 6x4 8x4 tipper 15tons 20ton sand transport sino truck trucks dump truck
Specification
Cabin
Driving type 4x2
HW70 cabin with A/C, 70°hydraulically tillable to the front as attached photo for ref.
Vehicle Main Dimensions
Overall dimensions (L x W x H)mm
7700×2500×3400
Wheel base (mm)
4600
Wheel track (front/rear) (mm)
2022/1830
Weight in KGS
Tare Weight
9000
payload
16000
Front axles loading capacity
1x9000
Rear axles loading capacity
1x16000
Max. driving speed（km/h）
85
Engine
Brand
SINOTRUK
Model
WD615.87
Type
4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, high pressure common rail
Horse Power（HP)
290
Emission standard
Euro II
Gearbox
HW15710, 10 Forwards gear & 2 reverse gear
Clutch
Reinforced diaphragm clutch, diameter 430 mm
Steering Gear
ZF 8118,power steering, hydraulic steering with power assistance
Fuel tank (L)
300 liters Aluminium oil tank
Tire
12R22.5 tubeless tyre, 11 pieces including one spare tire
Brakes
Service brake: dual circuit compressed air brake
Parking brake :(emergency brake): spring energy, compressed air operating on rear wheel
Bin size
4800*2300*1500 mm made of high tensile steel 700, side 4 and floor 5 mm thick
Hydraulic system
Middle tipping, T type
Packing & Delivery
SINOTRUCK HOWO chinese dump 6x4 8x4 tipper 15tons 20ton sand transport sino truck trucks dump truck
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
SINOTRUCK HOWO chinese dump 6x4 8x4 tipper 15tons 20ton sand transport sino truck trucks dump truck
SINOTRUK is one of the biggest heavy duty truck manufacturer in China, also the absolute No. 1 for exporting. We manufacture HOWO tractor truck, dump truck, concrete mixer, tanker truck, flat bed semi trailer etc. In 1983, SINOTRUK successfully introduced STEYR heavy duty truck project, in 2009, SINOTRUK signed an agreement with MAN from Germany, MAN becomes the second largest shareholder of SINOTRUK and is introducing its cabin, engine, axle and other parts into China. We, SINOTRUK Hubei Huawin is one of SINOTRUK factory, professional in producing different special purpose trucks.
FAQ
FAQ
1. MOQ: 1 unit
2. Optional payment terms: T/T or L/C
T/T: 30% deposit by T/T, 70% balance should be paid before shippment.
L/C: 30% payment advance, 70% L/C at sight.
3. Parts of famous brand can be adopted by your requirement, such as WABCO, JOST, BPW, FUWA.
4. Delivery time: Within15 workdays after receiving 30% deposit of T/T

Warranty
1. One year quality guarantee for three key parts axles, engine, transmission or within 100000km, which comes the first.
2. Other spare parts could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. The overseas engineers are always ready to deal with unexpected needs.
