3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder
3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder
3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder
3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder
3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder
3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder
Specifications
Brand Name :
Sindara steel
Model Number :
3PE Epoxy Powder Coating
Certification :
ISO 9001, ISO 14001, ISO 45001, CE
Place of Origin :
China
MOQ :
1TON
Price :
100USD-5000USD
Payment Terms :
L/C, T/T
Supply Ability :
1000000 TON
Delivery Time :
10-30DAYS
Packaging Details :
Carton outer packing, lined with polyethylene bag
Description
Description

3LPE (Standard CSA Z245.21-2022) (1B)

The epoxy powder coating is the implementation of CSA Z245.21-2022 standard, which is the bottom design of the three-layer structure of polyethylene in buried steel-made pipe, using appropriate epoxy resin, curing agent, pigment, filler, etc., and can form a composite anticorrosion system with excellent performance with intermediate layer adhesive and outer polyethylene.

1. Application scope and characteristics

● External anticorrosion of steel pipe and pipe fittings.

● Compared with other forms of anti-corrosion, it has the characteristics of good adhesion, strong cathode disbondment, and collision and damage prevention.

● It has the characteristics of mature process, wide application range, long anti-corrosion life, and wide operating temperature range (-40℃ ~80℃).

2. Method and dosage

1 .Coating method: Electrostatic spraying.

2 .Theoretical dosage: 150g/M2/100μm.

3 .Surface treatment: Sandblasting or Pelblasting.

4 .Curing instructions: Apply the powder coating on the surface of 180~220℃. When the powder coating forms a gelatinized state, the middle adhesive layer is squeezed and wound, so that the two layers are integrated into one, and then wrap the polyethylene layer, and finally form a complete three-layer coating structure.

3.Production Department

3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder 3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder 3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder

4. Paking

3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder 3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder 3 LPE Epoxy Powder Coating Three-layer structure polyethylene anti-corrosion layer bottom epoxy powder
