Mould Making Vertical Machining Center 1500kg Max Load Capabilities S-HV15

Introduce

The machine includes a bed, a column, a cross slide, a table, a headstock, and six support horns are placed under the bed to secure the machine.Each casting of the machine tool adopts a box-shaped structure and a hard cast iron material. The column is fixed on the bed body, and a Z-axis linear guide is added on the column, and the spindle box moves up and down along the Z-axis linear guide. A Y-axis linear guide is attached to the bed, and the cross slide moves forward and backward along the Y-axis linear guide. The table moves to the left and right along the X-axis linear guide mounted on the cross slide.
The bucket magazine, lubrication system and pneumatic control system are mounted on the left side of the column, and the electrical control equipment is mounted on the bracket at the right rear of the bed. The overall machine tool is compact and well arranged.

Product advantage:

1. H15 vertical machining center x/y axis are linear guide way adopt PMI/HIWIN brand.
2. Machine base is box type design, coordinate with large span stand column, it is more wider 40% than other same type machine tool, the design is conform to mechanics principle.
3. Adopts C3 grade high precision ball screw and pre-pull treatment bearing to ensured the rigidity and precision.
4. The casting of machine tool is high-grade, high quality gray casting iron with aging treatment, ensure the precision and lengthen the working life of machine tool.

Application Area

Widely used large parts for heavy cutting auto parts, hardware, medical devices and other industries.

Product Parameters

Standard Accessories:

Fanuc/Mitsubishi Controller system

Full enclosed cover

Spindle encoder position system

Auto lubrication system

Pneumatic system

RS 232 Interface

Operation unit

Working light

Tool and tool box

Optional accessories:

Siemens controller or other controller system

Spindle oil coolant

Umbrella type tool magazine

Arm type tool magazine

Chain type tool magazine

4 Axis rotary table

optical probe

tool setter

FAQ

Q1: How can I get a quotation of the cnc vertical machining center?
A: Leave us messages with your requements, we will reply to you within 12 hours. And you may contact us directly by Trade Manager or mobile.

Q 2: How to operate and maintain the machine?

A : First, we will provide a professional and detailed USER GUIDE to you with the machine; Second, we will debug the machine in the best status for you; At last, we also provide abroad technical training service.

Q 3: Where is your factory located ? How can I visit it ?
A : Our factory is located in shenzhen city,guangdong province,China. You can fly to shenzhen air port, we will pick you up.

Q 4 :What’s the delivery time, and what’s the package?

A : Normally the delivery time is about 30-45 days. All our CNC machines are packed with seaworthy package.

Q 5: Can you guarantee you quality?

A : Of course. We are the ferrous metal and non-ferrous metal foundry production series sand core machine manufacture factory ,more important, we put a high value on our reputation. Best quality is our principle all the time. You can be assured on our production completely.

Q 6: How long is the warranty for machines?
A : Machines warranty is 12 months after receive goods. in Warranty time,we can provide new free parts for changing.
