Automatic Hole Drilling Machine for FR4 & Fiberglass Sheets
Automatic Hole Drilling Machine for FR4 & Fiberglass Sheets
Automatic Hole Drilling Machine for FR4 & Fiberglass Sheets
Automatic Hole Drilling Machine for FR4 & Fiberglass Sheets
Automatic Hole Drilling Machine for FR4 & Fiberglass Sheets
Automatic Hole Drilling Machine for FR4 & Fiberglass Sheets
Automatic Hole Drilling Machine for FR4 & Fiberglass Sheets
Automatic Hole Drilling Machine for FR4 & Fiberglass Sheets
Specifications
Model Number :
SLTJ-6520
Drill bit service life :
1-5 million cycles
MOQ :
1
Payment Terms :
T/T
Certification :
CE
Color :
Grey
Supply Ability :
30 per month
Packaging Details :
L2150 x W1800 x H1450mm
Brand Name :
SILITRON
Material of drill bit :
SKD11/61 quenched
Place of Origin :
China
Precision :
±0.015mm
Description

Application Fields

It is suitable for single-layer rigid PCB, FR4 boards, acrylic sheets, and other fragile plastic sheet materials,


Product Features

1. CCD Image Precise Positioning.

2. CCD Automatic Positioning + Secondary Compensation.

3. High Drilling Accuracy up to ±0.02 mm.

4. Automatic Feeding System.

5. NC Servo Feeding.

6. Fast Automatic Drilling

7. Advanced Target Recognition

8. Three-Color CCD Light Source.

9. Multi-Hole & Multi-Side Drilling.


Technical Parameters

Model

SLTD-6520

Hole diameter

Φ1 mm-Φ5mm

Max material size

 650 * 520mm (MAX)

Min material size

260*100mm

Multiple light sources

white & colors

Material thickness

0.1-1.2mm(depend on material)

Punching precision

±0.02mm

Punching speed

0.3s/hole(exclude loading & unloading time)

Air pressure requirement

0.4~0.8Mpa

Power supply

AC 220V 60HZ 1KW

Storage height

280 mm

Dimension

 L1460mm x W1500mm x H1200mm

Weight

600kg



Workable Marks


Main Components

  • Transmission components: motor, lead screw, guide rail, slider, coupling, bearing, limit photoelectric switch, metal connecting plate.
  • Pneumatic components: solenoid valve, cylinder, oil–water filter, punching die, control relay.
  • Vision components: video capture card, camera, lens, infrared light source, touchscreen display.
  • Control components: industrial PC, motion control card, SLT automatic punching software, camera auto-positioning calculation system, relay on/off control system.
  • Electrical components: AC–DC power supply, short-circuit protection air switch, driver, solenoid valve.
