Specifications
Brand Name :
Yaoxing
Place of Origin :
China
MOQ :
Negotiable
Price :
USD1.5-30/m2
Payment Terms :
T/T
Supply Ability :
300000 kilograms per month
Delivery Time :
5-15 work days
Packaging Details :
PVC bags
Application :
Insulation, Fireproofing, Welding Protection
Yarn Type :
E-Glass
Width :
1m
Fabric Type :
Woven
Roll Length :
50 metres
Silicone Side :
Double Side
Working Temperature :
200 Degrees Celsius
Matreial :
Silicone and fiberglass
Description

Fireproof Silicone Coated Fiberglass Fabric 0.3mm For Building Fire Doors


Ⅰ. Description


Fireproof silicone coated fiberglass fabric is composed of glass fiber cloth and silicone rubber, which are combined through a specialized process.

Our silicone-coated fiberglass fabrics exhibit exceptional temperature resistance, allowing for prolonged use in environments ranging from -40°C to +200°C. These fabrics offer enhanced strength, thermal insulation, fire protection, and electrical insulation properties. Additionally, they possess water repellency, excellent chemical resistance, oil resistance, weather resilience, and abrasion resistance.

Applications for these materials include fire doors, welding protection gear, fire blankets, fabric pipe connectors, fire curtains, expansion joints, removable insulation sleeves, and more.


Ⅱ. Specification of Silicone-Coated Glass Fabric


Thickness

(mm)

Colour

Width

(m)

Length

(m/roll)

Working Temperature

(℉)

Gram per square meter

(g/m2)

Breaking Down Voltage

(KV/MM)

1.0 Red/Black and so on 1/1.2 50 392 1650 20
1.5 Red/Black and so on 1/1.2 50 392 2450 25
2.0 Red/Black and so on 1/1.2 50 392 3300 30
2.5 Red/Black and so on 1/1.2 50 392 4100 40
3.0 Red/Black and so on 1/1.2 25 392 4800 50


Ⅲ. Characteristics


1. Good temperature resistance: can be used for a long time between the low temperature -40 ℃ to high temperature 200℃.

2. High temperature is not easy to degumming, low temperature is not easy to be brittle.

3. Fire retardant, not easy to produce molten droplets when in contact with open flames, difficult to combust.

4. Resistance to ozone, oxygen, light and weather, anti-aging, weathering of the wild use of excellent, durable.

5. Has a high degree of insulating performance.

6. Good resistance to chemical corrosion resistance, oil resistance, oil stains, sealing and waterproof, can be scrubbed.

7. High strength, good adhesion, not easy to peel off, sewing is not easy to fall off the chip.

8. Soft and tough, easy processing.


Ⅳ. Buyer's Notice


1. Regarding delivery time: It will take 7 to 25 days after receiving your payment bank receipt. The specific delivery time depends on the products and quantity you ordered.
2. Regarding samples: We can provide a small sample of regular products for your quality test free of charge. The freight is payable.

3. Regarding customization: The specifications and dimensions of the products can be customized according to the customer's requirements. Therefore, it is necessary to contact and make a reservation in advance when purchasing.
