10mm Dia. 125C 2:1 Black Polyolefin Heat Shrink Tubing 600V VW-1
10mm Dia. 125C 2:1 Black Polyolefin Heat Shrink Tubing 600V VW-1
10mm Dia. 125C 2:1 Black Polyolefin Heat Shrink Tubing 600V VW-1
10mm Dia. 125C 2:1 Black Polyolefin Heat Shrink Tubing 600V VW-1
10mm Dia. 125C 2:1 Black Polyolefin Heat Shrink Tubing 600V VW-1
10mm Dia. 125C 2:1 Black Polyolefin Heat Shrink Tubing 600V VW-1
10mm Dia. 125C 2:1 Black Polyolefin Heat Shrink Tubing 600V VW-1
10mm Dia. 125C 2:1 Black Polyolefin Heat Shrink Tubing 600V VW-1
Specifications
Brand Name :
Sunbow
Model Number :
SB-RSFR-125H
Certification :
UL no E360625,RoHS/REACH
Place of Origin :
CHINA
MOQ :
1000m
Price :
USD0.09-16.4 per meter
Payment Terms :
Western Union, T/T,paypal
Supply Ability :
9,000,000 meters per month
Packaging Details :
packing by rolls,50-200m/roll
Characteristics :
Halogen free, non-smoke, non-toxic, flame-retardant, soft, quick shrink, stable performance
Shrink ratio :
shrink ratio 2:1
Working temperature :
-45ºC ~ 125ºC
Shrink temperature :
84ºC ~ 120ºC
Color :
black,blue,grey,red......
Size :
inner diameter 0.6-250mm
Product Name :
10mm Dia. 125C 2:1 Black Polyolefin Heat Shrink Tubing 600V VW-1
Description

10mm Dia. 125C 2:1 Black Polyolefin Heat Shrink Tubing 600V VW-1

Characteristics

1.Halogen free, non-smoke, non-toxic, flame-retardant, soft, quick shrink, stable performance

2.Shrink ratio: 2:1

3.Shrink temperature: 84ºC ~ 120ºC

Specification

Property

Unit

Test Method

Standard

Tensile Strength

MPA

≥10.4(Before Aging)

GB/T 1040

≥7.3(After Aging)

158ºC*168hrs

Breakage Elongation (%)

%

≥200(Before Aging)

GB/T 1040

≥100(After Aging)

158ºC*168hrs

Heat Shock

-

No Sticking & No Cracking

250ºC*4hrs

Cold Blend

-

No Cracking

-30ºC*4hrs

Breakdown Strength

KV/mm

≥15

GB/T 1408

Dielectric Withstand

600V

-

Pass

No Breakdown for 2500V, 60s

300V

-

Pass

No Breakdown for 1500V,60s

Volume Resistivity

Ω. cm

≥1×1014

GB/T 1410

Corrosion Performance

-

pass

158ºC*168hrs

Copper Stability

-

pass

158ºC*168hrs

Flammability

-

pass

VW-1

Dimension

Halogen free flame-retardant heat shrinkable tube

Inner

Diameter

As Supplied(mm)

After Recovery(mm)

Standard Package

Application Range(mm)

Inner Diameter

Wall Thickness

Inner Diameter

Wall Thickness

(m/spool)

Φ0.6

0.9±0.2

0.20±0.05

≤0.40

0.33±0.10

400

0.4~0.7

Φ0.8

1.1±0.2

0.20±0.05

≤0.50

0.33±0.10

400

0.6~0.8

Φ1.0

1.5±0.2

0.20±0.05

≤0.65

0.36±0.10

400

0.75~0.9

Φ1.5

2.0±0.2

0.20±0.05

≤0.85

0.36±0.10

400

0.95~1.4

Φ2.0

2.5±0.2

0.23±0.05

≤1.00

0.45±0.10

400

1.1~1.8

Φ2.5

3.0±0.2

0.23±0.05

≤1.30

0.45±0.10

400

1.35~2.3

Φ3.0

3.5±0.2

0.23±0.05

≤1.50

0.45±0.10

400

1.6~2.7

Φ3.5

4.0±0.2

0.23±0.05

≤1.80

0.45±0.10

400

1.85~3.2

Φ4.0

4.5±0.2

0.25±0.05

≤2.00

0.45±0.10

400

2.1~3.6

Φ4.5

5.0±0.2

0.28±0.05

≤2.30

0.56±0.10

200

2.35~4.0

Φ5.0

5.5±0.2

0.28±0.05

≤2.50

0.56±0.10

200

2.6~4.5

Φ6.0

6.5±0.2

0.28±0.05

≤3.00

0.56±0.10

200

3.1~5.4

Φ7.0

7.5±0.3

0.28±0.05

≤3.50

0.56±0.10

100

3.7~6.3

Φ8.0

8.5±0.3

0.30±0.08

≤4.00

0.56±0.10

100

4.2~7.2

Φ9.0

9.5±0.3

0.30±0.08

≤4.50

0.56±0.10

100

4.7~8.0

Φ10

10.5±0.3

0.30±0.08

≤5.00

0.56±0.10

100

5.2~9.0

Φ11

11.5±0.3

0.30±0.08

≤5.50

0.56±0.10

100

5.7~10

Φ12

12.5±0.3

0.30±0.08

≤6.00

0.56±0.10

100

6.2~11

Φ13

13.5±0.3

0.30±0.08

≤6.50

0.56±0.10

100

6.7~12

Φ14

14.5±0.3

0.35±0.10

≤7.00

0.70±0.10

100

7.3~13

Φ15

15.5±0.4

0.35±0.10

≤7.50

0.70±0.10

100

7.8~14

Φ16

16.5±0.4

0.35±0.10

≤8.00

0.70±0.10

100

8.3~15

Φ17

17.5±0.4

0.35±0.10

≤8.50

0.70±0.10

100

8.8~16

Φ18

19.0±0.5

0.35±0.10

≤9.00

0.70±0.10

100

9.3~17

Φ20

22.0±0.5

0.35±0.10

≤10.00

0.83±0.15

100

10.4~19

Φ22

24.0±0.5

0.40±0.12

≤11.00

0.83±0.15

100

11.4~21

Φ25

26.0±0.5

0.40±0.12

≤12.50

0.90±0.15

50

12.8~24

Φ28

29.0±0.5

0.45±0.12

≤14.00

0.90±0.15

50

14.4~29

Φ30

31.5±1.0

0.45±0.12

≤15.00

1.00±0.15

50

16~29

Φ35

36.5±1.0

0.45±0.12

≤17.50

1.00±0.15

50

18~34

Φ40

41.5±1.0

0.45±0.12

≤20.00

1.00±0.15

50

21~39

Φ45

46.5±1.0

0.50±0.15

≤22.5

1.00±0.15

25

23.5~44

Φ50

≥50

0.50±0.15

≤25.0

1.10±0.15

25

26~49

Φ60

≥60

0.60±0.15

≤30.0

1.20±0.15

25

35~55

Φ70

≥70

0.65±0.15

≤35.0

1.30±0.20

25

40~65

Φ80

≥80

0.65±0.15

≤40.0

1.30±0.20

25

45~75

Φ90

≥90

0.65±0.15

≤45.0

1.30±0.20

25

50~85

Φ100

≥100

0.65±0.20

≤50.0

1.30±0.20

25

55~95

Φ120

≥120

0.65±0.20

≤60.0

1.30±0.20

25

65~115

Φ150

≥150

0.65±0.20

≤70.0

1.30±0.20

25

80~145

Φ180

≥180

0.65±0.30

≤90.0

1.30±0.30

25

95~175

Φ210

≥210

0.65±0.30

≤105.0

1.30±0.30

25

110~205

Φ230

≥230

0.65±0.30

≤115.0

1.30±0.30

25

120~225

Φ250

≥250

0.65±0.30

≤125.0

1.30±0.30

25

130~240

2. halogen free flame-retardant ultra thin heat shrinkable tube

Inner

Diameter

As Supplied(mm)

After Recovery(mm)

Package

Application Range (mm)

Inner Diameter

Wall Thickness

Inner Diameter

Wall Thickness

(m/spool)

Φ0.6CB

0.9±0.2

0.13±0.05

≤0.40

0.20±0.10

200

0.4~0.7

Φ0.8CB

1.0±0.2

0.13±0.05

≤0.50

0.20±0.10

200

0.6~0.8

Φ1.0CB

1.40±0.20

0.13±0.05

≤0.65

0.20±0.10

200

0.7~1.0

Φ1.5CB

1.90±0.20

0.13±0.05

≤0.85

0.20±0.10

200

0.9~1.4

Φ2.0CB

2.40±0.20

0.13±0.05

≤1.00

0.22±0.10

200

1.1~1.8

Φ2.5CB

2.90±0.20

0.13±0.05

≤1.30

0.25±0.10

200

1.4~2.3

Φ3.0CB

3.40±0.20

0.13±0.05

≤1.50

0.28±0.10

200

1.6~2.7

Φ3.5CB

3.90±0.20

0.13±0.05

≤1.80

0.28±0.10

200

1.9~2.3

Φ4.0CB

4.40±0.20

0.15±0.05

≤2.00

0.30±0.10

200

2.1~3.6

Φ4.5CB

4.90±0.20

0.15±0.05

≤2.30

0.30±0.10

100

2.4~4.0

Φ5.0CB

5.50±0.20

0.15±0.05

≤2.50

0.32±0.10

100

2.6~4.5

Φ6.0CB

6.50±0.20

0.15±0.05

≤3.00

0.32±0.10

100

3.1~5.4

Φ7.0CB

7.50±0.30

0.15±0.05

≤3.50

0.32±0.10

100

3.7~6.3

Φ8.0CB

8.50±0.30

0.15±0.05

≤4.00

0.32±0.10

100

4.2~7.2

Φ9.0CB

9.50±0.30

0.15±0.05

≤4.50

0.35±0.10

100

4.7~8.0

Φ10CB

10.50±0.30

0.15±0.05

≤5.00

0.35±0.10

100

5.2~9.0

Φ11CB

11.50±0.30

0.18±0.05

≤5.50

0.40±0.10

100

5.7~10.0

Φ12CB

12.50±0.30

0.20±0.05

≤6.00

0.40±0.10

100

6.2~11.0

13CB

13.50±0.30

0.20±0.05

≤6.50

0.40±0.10

100

6.7~12.0

Φ14CB

14.50±0.30

0.20±0.05

≤7.00

0.40±0.10

100

7.3~13.0

Φ15CB

15.50±0.40

0.20±0.05

≤7.50

0.40±0.10

100

7.8~14.0

Φ16CB

16.50±0.40

0.22±0.05

≤8.00

0.40±0.10

100

8.3~15.0

Φ17CB

17.50±0.40

0.22±0.05

≤8.50

0.40±0.10

100

8.8~16.0

Φ18CB

18.50±0.40

0.22±0.05

≤9.00

0.42±0.10

100

9.3~17.0

Φ20CB

20.50±0.50

0.25±0.05

≤10.0

0.45±0.10

100

10.5~19.0

Φ22CB

22.50±0.50

0.25±0.05

≤11.0

0.45±0.10

100

11.5~20.5

Color:Standard color is black,other color available upon request

Company information

Our main products include various fiberglass sleeving, silicone tube (especially the platinum cured silicone tube), PTFE tube, PVC tube, Heat shrinkable tube and so on.

All our products have obtained theUL and CSA certificates (Cert No: E333178 --UZIQ2, VW-1 & E333177--UZFT2/8,200C, 600V).Also all our products are in conformance with the European RoHS requirements. Furthermore, based on European new requirements, we re-apply and obtained German PFOA and PFOS certificates and European REACH reportshowing that our products do not contain 73 high-risk substances. In Sep.2009, we successfully passed ISO9001:2008international quality management system certification, nowISO14001system is also pushing.
