150*150mm 12V 100W Flexible Polyimide Film Heater
150*150mm 12V 100W Flexible Polyimide Film Heater
150*150mm 12V 100W Flexible Polyimide Film Heater
150*150mm 12V 100W Flexible Polyimide Film Heater
150*150mm 12V 100W Flexible Polyimide Film Heater
150*150mm 12V 100W Flexible Polyimide Film Heater
150*150mm 12V 100W Flexible Polyimide Film Heater
150*150mm 12V 100W Flexible Polyimide Film Heater
Specifications
Place of Origin :
JiangSu
Brand Name :
Hotlong
Certification :
ISO9001,UL,CE
Supply Ability :
50000 Piece/Pieces per Month
Packaging Details :
carton box
MOQ :
50-100
Price :
consultative
Delivery Time :
7-10
Condition :
New
Type :
polyimide film heater
Power Source :
Electric
Dimension(L*W*H) :
customized
Weight :
according to product
Voltage :
customized
Warranty :
1 YEAR
After-sales Service Provided :
Online support, Overseas service provided
Description

flexible polyimide film heating elements

Our heaters are made of fiberglass cloth impregnated with silicone rubber, which together provide great strength and flexibility. A wire heating element is then vulcanized between two layers of silicone rubber, forming a durable yet very flexible heat blanket that is resistant to moisture, chemicals, acids and many industrial solvents.

Size(mm)
Voltage(V)
Wattage(W)
Accessories
150*150
12V
100W
Adhesive, thermistor
160*160
12V
90W
Adhesive, thermistor
200*200
12V/24V
150W
Adhesive, thermistor
300*300
12V/24V
270W
Adhesive, thermistor
340*370
24V
250W
Adhesive, thermistor
Different size of silicone heater bed ,if you can't find suitable size ,please let me know. Also can supply 400x400mm ,500x500mm ,600x600mm big size heater bed.
Dimension
Dimensions on request
Thickness
1.5mm(standard) 4.5mm/6mm/7.5mm
Voltage
Any voltage on request
Output
Up to 5KW/M2
Tolerance
±10% on resistance
Min exposure temperature
-60°C
Max surface temperature
200°C
Application
150*150mm 12V 100W Flexible Polyimide Film Heater
Flexible polyimide film heating elements

Features:

1. Light-weight, thin thickness offer faster warm-ups and quicker response.

2. Very flexible offer thermal contact with the Part for maximum heating efficiency.

3. Offered in a virtually unlimited range of shapes, sizes and wattages.

4. Their flat etched foil elements cover more area and transfer heat more efficiently than wire wound designs.

5. On request, temperature distribute in the surface of the heater.

6. Small thermal lag, precision temperature control and fast response.

7. polyimide film insulation is dimensionally stable, self-extinguishing, and highly resistant to oils, chemicals, fungus, solvents and radiation.

8. Thermostats and other sensors may be integ rated into the design for accurate control and temperature tracing.

9. PSA is available as an option on heater rated at 1W/cm2 and 2W/cm2. The heater can be mechanically clamped or epoxy mounted by the user.

10. Very safety, realizable and long life.

150*150mm 12V 100W Flexible Polyimide Film Heater150*150mm 12V 100W Flexible Polyimide Film Heater150*150mm 12V 100W Flexible Polyimide Film Heater

Our Services

For one year guarantee period and the wroking life of design is 50000 hours to 100000 hours.

The specifications of heater can be custom design.
We devote to solve problems and provide solutions for you on heating field.
Features
1. Reliability.
PVC outer coat and non-woven glass fiber cotton for heat preservation, Service life can reach 15 years or more.
2. Easy installation, excellent flexibility, explosion-proof joint is available when necessary.
3. Aesthetic appearance.
Specification
1. Maximum resisting temperature of inner tube: 250(PFA)
2. Inner resisting pressure: 10 KG f/cm2(150℃)
3. Maximum resisting temp. of outer coat:
105℃
4. Inner maintenance temp.:140℃(40W/m)
5. Lowest installation temp.: -9℃
6. Max contact temp.: 60℃
7. Heat transfer coefficient of insulation layer: 2.6W/m2·℃
8. Working voltage, power: 220V, 40W/m2
