Specifications
Place of Origin :
JiangSu
Brand Name :
Hotlong
Certification :
ISO9001,UL,CE
Supply Ability :
15000 Piece/Pieces per Month
Packaging Details :
carton box
MOQ :
50-100
Price :
consultative
Delivery Time :
7-10
Condition :
New
Type :
polyimide film heater
Power Source :
Electric
Dimension(L*W*H) :
as request
Weight :
as product
Voltage :
as request
Warranty :
1 YEAR
After-sales Service Provided :
Online support, No overseas service provided
Material :
polyimide film
Port :
Shanghai
Description

polyimide film polyimide flexible heater

Features:

1. Light-weight, thin thickness offer faster warm-ups and quicker response.

2. Very flexible offer thermal contact with the Part for maximum heating efficiency.

3. Offered in a virtually unlimited range of shapes, sizes and wattages.

4. Their flat etched foil elements cover more area and transfer heat more efficiently than wire wound designs.

5. On request, temperature distribute in the surface of the heater.

6. Small thermal lag, precision temperature control and fast response.

7. polyimide film insulation is dimensionally stable, self-extinguishing, and highly resistant to oils, chemicals, fungus, solvents and radiation.

8. Thermostats and other sensors may be integ rated into the design for accurate control and temperature tracing.

9. PSA is available as an option on heater rated at 1W/cm2 and 2W/cm2. The heater can be mechanically clamped or epoxy mounted by the user.

10. Very safety, realizable and long life.

Self Extinguishing Insulation Lightweight Thin Flexible Polyimide HeaterSelf Extinguishing Insulation Lightweight Thin Flexible Polyimide HeaterSelf Extinguishing Insulation Lightweight Thin Flexible Polyimide HeaterSelf Extinguishing Insulation Lightweight Thin Flexible Polyimide HeaterSelf Extinguishing Insulation Lightweight Thin Flexible Polyimide Heater

Specification
1. Maximum resisting temperature of inner tube: 250(PFA)
2. Inner resisting pressure: 10 KG f/cm2(150℃)
3. Maximum resisting temp. of outer coat:
105℃
4. Inner maintenance temp.:140℃(40W/m)
5. Lowest installation temp.: -9℃
6. Max contact temp.: 60℃
7. Heat transfer coefficient of insulation layer: 2.6W/m2·℃
8. Working voltage, power: 220V, 40W/m2
Installation instructions
Our product is available to cut according to specific needs. About 0.5m should be obligated after cutting.
Carefully separate the plate and inner tube. The cutting part should be cone shape and well taped to avoid damaging. Flaring type joint is used to connect inner tube and equipment.
Connecting box is recommended to connect the power and heater. All the accessories can be provided by Hotlong.

Our Services

For one year guarantee period and the wroking life of design is 50000 hours to 100000 hours.
The specifications of heater can be custom design.
We devote to solve problems and provide solutions for you on heating field.
