Flexible Silicone Electronic Potting Gel Material For Electronic Components
Flexible Silicone Electronic Potting Gel Material For Electronic Components
Specifications
Brand Name :
Hanast
Model Number :
HN-8806AB
Certification :
ROHS SGS
Place of Origin :
Guangdong, China
MOQ :
1kg
Price :
Negotiable
Payment Terms :
T/T
Packaging Details :
25KG/barrel
Hardness :
45-55 shore A
Customized :
Support
Sample :
Free sample
Feature :
Flexible ,good electrical properties and Thermal conductivity
Application :
Electronic Components,led,PCB,battery
Thermal conductivity :
Can be customized
Description

Flexible Silicone Potting Material for electronic components Two-component addition type Waterproof Silicone Potting Compound Grey Low Viscosity 1:1 Silicone

PRODUCT DESCRIPTION

HN-8806, two-component addition type silicone potting rubber which can be cured into high-performance elastomer by room temperature or heating.

This potting silicone rubber has excellent electrical insulation, high moisture resistance, and a wide temperature range of -50°C to 250°C.

Product features:

Low-viscosity potting compound that Will cure in deep sections. Low shrinkage rate after curing, will not emit heat and by-products, no corrosion for filling and sealing components.

No pollution in the surrounding environment, Complying with RoHs standards.

Its good thermal conductivity function can effectively transfer the heat emitted by the electronic components.

Test Items Test Standard Units Product test results
Part A Part B

Before

Curing

 1 Appearance By eyes --- Grey, fluid White, fluid
2 Viscosity GB/T10247- 2008 25ºC,mPa·S 4500~5000 4500~5000
3 Density GB/T 13354-92 25ºC,g/cm3 1.50±0.05 1.50±0.05
4 Mixing Ratio (A : B) 1:1 Weight ratio 100 100
Volume ratio 100 100
5 Operating time Measured hr 0.3-0.4
6 Curing condition Measured hr

4~12

(25ºC, initial cure)

0.20

(80ºC)

After

Curing

 7 Appearance By eyes --- Grey Elastomer
8 Hardness GB/T 531.1-2008 Shore A 50±5
9 Thermal conductivity GB/T10297-1998 w/m·k ≥0.76
10 Expansivity GB/T20673-2006 µm/(m,ºC) 210
11 Moisture Absorption GB/T 8810-2005 24h,25ºC,% 0.01~0.02
12 Volume resistivity GB/T 1692-92 (DC500V),Ω· cm 1.0×1016
13 Dielectric intensity GB/T 1693-2007 Kv/mm(25ºC) 18~25
14 Temperature Resistance Measured ºC -50~+250

​​

* Packing *

10KG / Set (A, 5kg + B, 5kg)

20KG / Set (A, 10kg + B, 10kg)

50KG / Set (A, 25kg + B, 25kg)

- Storage and transportation:

This product is non-toxic non-dangerous goods, according to the general chemical handling, stored in a cool & dry place (room temperature).

- Shelf Life: 6 months, overdue please reinspect; If it meets the standard, it can still be used.
