Specifications
Model Number :
HN-8820
Packaging Details :
50KG/set, 25KG/bar
MOQ :
1-2KG
Hardness :
50±5 SHORE A
Cusomization :
Support
Color :
Grey,white,black
Application :
New Energy Vehicle Power Batteries and Thermal Management Systems
Name :
silicone potting compound for electronics
Price :
Negotiable
Payment Terms :
T/T、paypal
Shelf time :
6months
Features :
2.0 thermal conductivity
Place of Origin :
Guangdong, China
Brand Name :
Hanast
MOQ :
1KG
Delivery Time :
5-7days
Supply Ability :
100ton/month
Mix ratio :
1:1
wide temperature range :
-50°C to 250°C
Certification :
ROHS
Description

Battery Cell Module Potting 2.0 High Thermal Conductivity Silicone Potting Compound 1:1


Product Overview for silicone potting compound:
High-conductivity potting compound is a two-component, thermally conductive silicone potting material. Utilizing an addition-curing silicone rubber system, it consists of two components—A and B—which, after being mixed in a 1:1 ratio, cure at room or moderate temperatures. The curing process generates no low-molecular-weight byproducts and exhibits low shrinkage. Its thermal conductivity can reach up to 3.0 W/m·K.

Battery Cell Module Potting 2.0 High Thermal Conductivity Silicone Potting Compound 1:1

Technical Parameters for silicone potting compound:

Exterior:grey liquid
viscosity:2000-3000cps
hardness:45-50shore A
thermal conducitivity:2.0(W/M▪K)
Flame retardant rating (V) (UL94):V-0
Wide temperature range (-40℃-150℃)

Battery Cell Module Potting 2.0 High Thermal Conductivity Silicone Potting Compound 1:1

Product Applications for silicone potting compound:

5G Communications, Microinverters, and Precision Electronics; Third-Generation Semiconductors and Power Module Packaging; New Energy Vehicle Power Batteries and Thermal Management Systems

Battery Cell Module Potting 2.0 High Thermal Conductivity Silicone Potting Compound 1:1




How to use silicone potting compound:

  • Weigh & Stir: Accurately weigh components A and B in a 1:1 ratio. Stir each part thoroughly before mixing to disperse any settled fillers and ensure consistent performance.
  • Mix Thoroughly: Blend the two parts (by hand or machine) until the color is completely uniform. Tip: If mixing manually, work in small batches so the glue stays fluid and easy to pour.
  • Degas: Place the mixed glue into a vacuum chamber to completely remove any trapped air bubbles. [1]
  • Pot: Pour the bubble-free glue into your device. Tip: Ensure your device and mixing containers are completely clean and dry before starting.

Battery Cell Module Potting 2.0 High Thermal Conductivity Silicone Potting Compound 1:1
