12V 3W Edge Emitting LED Module IP65 300LM Slim Design for Light Box Signage
12V 3W Edge Emitting LED Module IP65 300LM Slim Design for Light Box Signage
12V 3W Edge Emitting LED Module IP65 300LM Slim Design for Light Box Signage
12V 3W Edge Emitting LED Module IP65 300LM Slim Design for Light Box Signage
12V 3W Edge Emitting LED Module IP65 300LM Slim Design for Light Box Signage
12V 3W Edge Emitting LED Module IP65 300LM Slim Design for Light Box Signage
Specifications
Model Number :
Box3Max-MFK042
Led Chip :
3030
MOQ :
1000pcs
Delivery Time :
5-15 working days
Led Color :
White 2700k-9000k
Brand Name :
SignLED
Product Name :
Edge Led Module
Packaging Details :
1000pcs/carton
Payment Terms :
T/T,Western Union,Paypal,L/C
Module Size :
74*20*9.5mm
Price :
0.8-0.85USD/Piece
Brand Logo :
Free Cost Logo
Supply Ability :
5000pcs/day
Application :
Advertising Displays
Certification :
CE ROHS
Warranty :
5 Years/ 50000 Hours
Place of Origin :
ShenZhen，China
Led Chain :
20pcs Chain
Description

12V 3W Edge Emitting LED Module IP65 300LM Slim Design for Light Box Signage


Optimized for advertising light boxes requiring side illumination to ensure bright and uniform lighting for channel letters and signage


Designed for standard DC12V systems allowing easy integration with existing LED power setups and versatile installation options


Features a space-saving structure that fits various cabinet designs and is backed by an IP65 waterproof rating for reliable long-term performance


Product Parameters:


Model No. LED Color CCT (K) Voltage Power LM Effect (LM/W) Angle
Box3Max-MFK042 3030 White 2700~9000K 12V/24V 3W 300 100 15*45°
Other Colors
Connection Qty Shell color Drive Method Weight (g/20pcs) Warranty W T(℃) ST(℃) IP Level
20pcs White Constant Voltage 260 5Years Or 50000H -25-+60 -25+80 IP65



Product Features:

Stable current performance ensures continuous and reliable lighting operation for extended periods, minimizing flicker and maintaining consistent brightness even during long-term use, ensuring a superior visual experience.


Efficient aluminum substrate design significantly enhances thermal management to prolong lifespan by effectively dissipating heat, ensuring the LED chips operate at optimal temperatures.


Wide optical control technology creates smooth and uniform panel illumination without dark spots or hotspots, providing a high-quality visual effect perfect for premium advertising displays.


12V 3W Edge Emitting LED Module IP65 300LM Slim Design for Light Box Signage


Led Module Applications:

Channel letter illumination


Narrow cabinet backlighting


Outdoor signage lighting


12V 3W Edge Emitting LED Module IP65 300LM Slim Design for Light Box Signage


FAQ:


Q: Can this module maintain consistent brightness during operation?
A: Yes, the module is designed to provide stable light output for continuous lighting applications.
Q: What installation factors should be considered for edge emitting modules?
A: Proper module spacing, mounting position, and light direction should be considered to achieve the desired illumination result.
Q: Why choose a 3W LED module for edge lighting projects?
A: The 3W design provides a balance between brightness and energy consumption, suitable for projects requiring stable illumination output.
