The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
Specifications
Type :
Centrifugal Fan, Cycle Ventilation
Applicable Industries :
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising C
Customized support :
OEM, ODM, OBM
Electric Current Type :
EC/DC/AC
Blade Material :
Plastic
Mounting :
FREE STANDING
Place of Origin :
Shandong
Brand Name :
Shuangyi
Model Number :
SY-S4
Voltage :
110v/220v/380V/480V
Warranty :
1 Year
After-sales Service Provided :
Online support
Core Components :
Motor, Belt
Product name :
Centrifugal Fan
Application :
Warehouse Workshop Logistic Center Gym
Height :
1000mm-
Installation :
Screw Fixing
Motor :
Explosion Proof
Usage :
Ventilator Outlet
Model :
Material
Function :
Ventilaion
Price :
$49.00/sets 1-19 sets
MOQ :
1 PC
Description
Products Description
The Popular Belt Coupling Driven Automation Fiberglass Centrifugal Fan
Application
S4-72-11 centrifugal ventilators are suitable for Petroleum, chemical industry, metallurgy, electroplating, sewage treatment,
brewing, textiles, electronics and other area. This fans are used for ventilation and air-change.
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
Specification
Advantage.
This ventilator has the features such as: High efficiency, low noise, stable pressure curve and anti-corrosion and energy
saving,convenient installation, wide application.
Model
This kind of centrifugal fan are divided in to A\C\D three connect way, type A means the motor connect with the impeller directly,
the C type means the motor and the impeller connected by the belt, type D means connected by the coupler. Material
The fans can be made of FRP material, steel material, stainless steel material, aluminum material, PP/PVC material.

Impeller

Motor

Air outlet

The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
Performance selection table
Machine number
Flow(m3/h)
Press completely(pa)
Power(kw)
2.8A
2450~1330
588~951
1.5
3.2A
3640~991
196~1245
1.1~2.2
3.6A
5408~1470
274~1618
.1.1~3
4A
7420~2010
333~2000
1.1~5.5
4.5A
10580~2860
420~2530
1.1~7.5
5A
14720~3977
549~3177
2.2~15
6A
12720~4250
343~1137
1.5~4
6C
19600~3780
226~2726
.1.1~18.5
6D
12720~4250
343~1137
1.5~4
8C
34800~7040
284~3119
2.2~30
8D
27990~8150
392~2020
3~18.5
10C
50150~13910
294~2344
3~37
10D
58200~20800
637~3158
7.5~55
12C
77500~19280
275~2717
3~75
12D
96500~3500
922~1579
18.5~37
Application
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
Product packaging
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
The Belt Coupling Driven Automation Fiberglass Centrifugal Fan for Warehouse Workshop
