Specifications
Model NO. :
BV
Application :
House Wire
Conductor Material :
Copper
Sheath Material :
PVC
Insulation Material :
PVC
Material Shape :
Round Wire
Range of Application :
Fire Resistant
Certification :
CE, CCC, RoHS
Brand :
Xinxin
Core :
Single Core and Multiple Core
Testing Voltage 5 Minute :
3.5kv
Rated Voltage :
0.6/1kv
Working Temp. of Conductor :
90ºC
Min.Installation Temp :
>0ºC
Transport Package :
Roll
Specification :
copper/PVC
Origin :
China
HS Code :
85444921
Supply Ability :
10km/Day
Description
Descriptions
Single-core non-sheathed cables with rigid conductor for general purposes
Code designation: 60227 IEC 05 (International), BV 300/500V(China)
H05VV-F/H05VV-R
Constructions
1.Conductor: Plain circular solid copper conductor, comform to IEC 60228 class 1
2.Insulation: PVC
Applications
Used as fixed wiring cable of rated voltage 300/500V.

Standards
International: IEC 60227
China: GB/T 5023-2008
Other standards such as BS, DIN and ICEA upon request

Technical data
Rated voltage:300/500 V
Max. Conductor Temp. in normal use: 70 ºC
Min. Bending Radius: 4 x cable O.D
Certificates
CE, RoHS, CCC, KEMA and more others at request
Specifications
