Specifications
Model NO. :
YJY YJV WDZ-YJY WDZ-YJV
Current :
DC & AC
Insulation Material :
XLPE
Sheath Material :
PE
Material Shape :
Round Wire
Wire Core Material :
Bare Copper Wire
Certification :
ISO, CCC, CE, RoHS
Model :
Yjy Yjv Wdz-Yjy Wdz-Yjv
Brand :
Xinxin
Color :
White/Black
MOQ :
500m
Conductor :
Copper
Insulation :
XLPE
Sheath :
PE
Transport Package :
Wooden Steel Drum
Specification :
1.1*1.1*0.98m
Trademark :
Shanghai Shenghua Cable Group
Origin :
Shanghai, China
HS Code :
8544492100
Supply Ability :
100000
Package Size :
110.00cm * 110.00cm * 75.00cm
Package Gross Weight :
800.000kg
Description

Product Name:YJY XLPE insulation LSOH Sheathed Flame retardant Power Cable

Description:
CU/XLPE/LSOH, IEC 60331
IEC 60502, IEC 60227, IEC 60331, IEC 601034, IEC60754 GB/T 12706-91 GB306.1-2001, GB/T18380.3-2001
CE, CCC, KEMA
Constructions
Conductor: Circular stranded copper conductor, conforms to IEC 60228 class 2
Insulation: XLPE/A
Inner Covering: LSOH
Sheath: LSOH , black
Note: Insulation color as per standards or customer requirement

Applications
Used for tall building, Hospital, Theatre, Power station, Metro Tunnel or Petrochemical Industry or other special place required for low smoke , zero halogen clean and safe cable.
Standards
International: IEC 60502, IEC 60227 IEC 60331, IEC 601034
China: GB/T 12706-91 GB306.1-2001, GB/T18380.3-2001
Other standards such as BS,DIN and ICEA upon request

Technical data
Rated voltage: 0.6-KV
Max. Conductor Temp.: normal (90ºC), short circuit no more than 5 s (the highest temperature of conductor shall no more than 250ºC )
Min. Ambient Temp.:The cable shall be pre heated if the ambient temperature is below 0ºC
Min. Bending Radius: single core cable 20(d+D)±5%
Multi-core cable 15(d+D)±5%
Product Name YJY XLPE Insulation LSOH Sheathed Flame Retardant Power Cable
Model/Standard CU/XLPE/LSOH, IEC 60331, IEC 60502, IEC 60227, IEC 60331, IEC 601034, IEC 60754, GB/T 12706-91, GB306.1-2001, GB/T18380.3-2001, CE, CCC, KEMA
Conductor Material Circular stranded copper conductor, conforms to IEC 60228 class 2
Insulation Material XLPE/A
Inner Covering LSOH
Sheath Material LSOH, black
Insulation Color As per standards or customer requirement
Rated Voltage 0.6 kV
Max. Conductor Temperature Normal: 90°C; Short circuit (5 seconds): Maximum conductor temperature not exceeding 250°C
Min. Ambient Temperature Cable should be preheated if ambient temperature is below 0°C
Min. Bending Radius Single-core cable: 20(d+D)±5%; Multi-core cable: 15(d+D)±5%
