Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Stonex S9II GPS Receiver UM980 Board Gnss Rtk
Specifications
Available :
Hard Plastic Case
Package Size :
55cm * 45cm * 70cm
Channels :
1408
HS Code :
8526919090
Package Gross Weight :
30kg
Brand Name :
Stonex
Model Number :
S9II
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
1000 per year
Packaging Details :
With Standard Packing Way
Customization: :
Available
IMUT Tilt Sensor :
Yes
Description

High Precision Survey Instruments Stonex S9II GNSS RTK GPS Receiver Base and Rover with UM980 main board and 1408 channels Tilt sensor IMU function

Stonex S9II GPS Receiver UM980 Board Gnss RtkStonex S9II GPS Receiver UM980 Board Gnss RtkStonex S9II GPS Receiver UM980 Board Gnss Rtk

Equipped with an advanced 1408 channels GNSS board and capable of supporting multiple satellite constellations, including GPS, GLONASS, BEIDOU and GALILEO, Stonex S3II GNSS receiver is an ideal solution for any surveying field work. The advanced receiver design gives S3II excellent signal tracking ability and interference resistant capacity.

The independent R&D LINUX+CORTEX intelligent platform provides users high performance computing and infinitely expanding. The unique internal antenna combines GNSS, Bluetooth and Wi-Fi integrated modules to optimize space and increase performance.

Advantages of portability and speed of operation make S3II GNSS receiver particularly suitable for fieldwork in areas of complex terrain. The Stonex S3II has built-in internal Bluethooth capability that allows the users to choose their data collector model and software.


Stonex S9II GPS Receiver UM980 Board Gnss Rtk

Model S9II
Satellite system Beidou+GPS+GLONASS+ Galileo
Track features Channel 1408
GPS L1 C/A,L2E,L2C,L5
GLONASS L1 C/A, L1P, L2 C/A(GLONASS M), L2P
BDS B1,B2
GIOVE-A L1 BOC, E5A, E5B, E5AltBOC1
GIOVE-B L1 CBOC, E5A, E5B, E5AltBOC1
SBAS WASS,MSAS,ENGOS,QZSS
Performance indicators Static measurement of plane precision. ±(2.5mm + 1ppm)RMS
Static measurement elevation accuracy. ±(5mm + 1ppm)RMS
RTK measures plane precision. ±(10mm + 1ppm)RMS
RTK measures elevation accuracy. ±(20mm + 1ppm)RMS
SBASPositioning (typical) Plane precision <1m 3DRMS
Elevation accuracy <5m 3DRMS
Initialization time <10s
Initialization reliability >99.99%
Environmental indicators Working temperature - 30ºC~+65ºC
Storage temperature - 40ºC~+80ºC
Waterproof and dustproof IP67
drop Resistance to 2 m drop (concrete hard ground)
Waterproof Immersing 1 meter in water (30 minutes)
humidity 100% condensation resistance
Memory and data Internal Storage Onboard 4G SD card expansion, maximum support 32G.
differential output RTCM2.3,RTCM3.0,RTCM3.X,CMR,CMR+
GNSS antenna performance The internal integrated quad-feeder microstrip antenna, zero-phase center, built-in multipath suppression plate.
bluetooth built-in,V2.0 Class2
Network communication Built-in WCDMA 3.5G network communication module;Customizable CDMA2000 3G network communication.
Wireless communications Communication protocol TrimTalk is interchangeable with international brand radio and can be customized with domestic hosts.
UHF radio Built-in transceiver 0.5W/2W
outer launch 5W/35W
Working frequency 410-470MHZ
Physical and power characteristics. size φ19cm×9.9cm
Weight 1.2kg
Battery capacity Single block 3400mAh
keys 2
service time 6 hours
industrial-grade controller P9 operating system Windows Mobile 6.5
Hardware platform AM335X frequency 1GHz
onboard memory RAM:512MB DDR3 onboard memory 4G
Display 3.7 inches Blanwiew TFT,480*640VGA resolution ratio
Battery 7.2V/3400mAH
Waterproof and dustproof IP67
Working temperature - 30ºC~+60ºC
Storage temperature - 30ºC~+70ºC
drop Resistance to 2 m drop (concrete hard ground)
camera 5 megapixel autofocus.
communication Wi-Fi bluetooth /USB OTG/3.5G
