Specifications
Payment Terms :
L/C,D/A,T/T,D/P,Western Union
Brand Name :
NA
Packaging Details :
Polybag, Carton, Wooden case or According to your request
Model Number :
OEM
MOQ :
Based on customer requirements
Delivery Time :
30-45 Days
Price :
NA
Supply Ability :
100000pcs/ month
Certification :
ISO13485
Place of Origin :
CN
Description

Customized Stainless Steel Spring Pin For Precision Instrument Assembly

Product Name Customized Stainless Steel Spring Pin For Precision Instrument Assembly
Material High-grade 6061/7075 aluminum alloy, lightweight with high structural rigidity
Processing Craft 5-axis CNC precision milling, one-time forming for complex profiles
Dimensional Tolerance ±0.01mm for key dimensions, meets high-precision assembly requirements
Hole Position Accuracy ±0.02mm positional tolerance between mounting holes, ensures seamless fitting
Surface Treatment Optional polishing, sandblasting, clear/colored anodizing for anti-corrosion
Structural Feature Custom multi-hole positioning layout, reserved mounting ports per drawings
Surface Finish Fully deburred inner and outer surfaces, no scratches or sharp edges
Applicable Scene Industrial mechanical equipment, automation devices, precision machinery assembly
Customization Service Full OEM support, adjustable size, hole pattern, surface finish and material

Customized Stainless Steel Spring Pin For Precision Instrument Assembly

Product Advantages:

  • Made of stainless steel 304 material, adopts ordinary surface finish.

  • Dimension tolerance up to ±0.02mm to guarantee stable elastic performance.

  • Excellent elastic recovery keeps consistent compression force for repeated use.

  • Compact coil structure, easy for installation inside precision instruments.

  • Wire diameter, coil count and free length can be customized per drawings.

  • Deburred surface prevents scratch damage to matching components.

FAQ:


Q: What is the main function of the spring pin?
A: The spring pin is a precision elastic component. It provides stable compression force for positioning, locking and resetting, widely used in medical devices and precision equipment assemblies.

Q: What are the advantages of stainless steel for this spring pin?
A: Stainless steel features good corrosion resistance and high fatigue resistance. It maintains stable elasticity after repeated compression, and is not easy to rust under humid working environment.

Q: What benefits does the compression spring structure have?
A: The compression spring structure can absorb pressure and automatically rebound. It ensures reliable contact and positioning between parts during equipment operation.

Q: What specifications of this spring pin can you customize?
A: We can customize wire diameter, outer diameter, free length, coil number and end shape according to customer drawings. Non standard sizes are available.

Q: What should be noted when using the spring pin?
A: Avoid exceeding the maximum compression limit during assembly. Prevent scratches on spring surface. Check elasticity regularly in long term running equipment.
