8U0827851 Automatic Power Lift Gate Audi Q3 Electric Tailgate Strut
8U0827851 Automatic Power Lift Gate Audi Q3 Electric Tailgate Strut
8U0827851 Automatic Power Lift Gate Audi Q3 Electric Tailgate Strut
8U0827851 Automatic Power Lift Gate Audi Q3 Electric Tailgate Strut
8U0827851 Automatic Power Lift Gate Audi Q3 Electric Tailgate Strut
8U0827851 Automatic Power Lift Gate Audi Q3 Electric Tailgate Strut
8U0827851 Automatic Power Lift Gate Audi Q3 Electric Tailgate Strut
8U0827851 Automatic Power Lift Gate Audi Q3 Electric Tailgate Strut
Specifications
Place of Origin :
China
Brand Name :
Depin
MOQ :
2 Pieces
Price :
Negotiable
Certification :
ISO CE
Packaging Details :
Carton Box
Delivery Time :
3-15days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000 Sets/month
Model Number :
8U0827851
Item Name :
Power Lift Gate
Condition :
New
Model :
Audi Q3
Year :
2016 - 2018
OE NO. :
8U0827851
Car Fitment :
Audi
Type :
Electric Tailgate Strut
Warranty :
12 Months
Description

8U0827851 8U0827852 8U0827851B Automatic Power Lift Gate for Audi Q3 Electric Tailgate Strut

Product Information

The electric strut consists of several key components, including a ball and socket, Hall sensor, motor, reducer, screw, nut, and spring. When the controller module sends a command, the motor activates in either the forward or reverse direction. The torque is amplified through the reducer, which drives the screw to rotate. This action creates relative motion between the screw and the nut. With the assistance of a compression spring, the stay rod can either extend or retract. Additionally, the Hall sensor located at the rear of the motor provides feedback to the controller, allowing it to manage the open and closed positions of the stay rod accurately.

Function

The electric tailgate offers several convenient features for users. It automatically opens and closes with a simple touch of a switch or remote control, making it easy to operate while carrying heavy items. High-end models provide height control, allowing users to adjust the tailgate's opening height to prevent head injuries or ensure adequate clearance. Additionally, the intelligent induction feature detects obstacles while closing, automatically stopping the tailgate to avoid harm. Users can also operate the tailgate using in-car buttons, remote keys, or a smartphone app for added convenience. Furthermore, the system can automatically determine the tailgate's movement state and reverse its operation as needed.

Some Models of Audi Electric Gas Struts

Model of Car Standard OEM Number
Audi A6C6 4GD823359
Audi A4 8T0823359
Audi A7 4G8823359A
Audi Q5 8R0823359A 80A827851A 80A827851N 80F827851A
Audi E-tron 4KE827851F
Audi Q8 4M8827851
Audi Q2 81A827851
Audi Q3 83A827851D 8U0827851
Audi A5 S5 SPORTBACK 8W8827851
