Specifications
Brand Name :
DOOWIN
Model Number :
OBP
Certification :
CCS, BV, ABS, ISO, SGS
Place of Origin :
Shandong, China
MOQ :
1 unit
Price :
USD 100~ USD 7800
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
500PCS/WEEK
Delivery Time :
2 weeks
Packaging Details :
carton, plywood box
Material :
PVC coated fabric
Technology :
HF welding seam
Capacity :
100kg~50ton
Standard :
IMCA D016
Safety factor :
5:1
OEM :
Yes
Description

IMCA Standard PVC Material Salvage Balloon Open Bottom Parachute Underwater Lifting Bags

Underwater lift bags are open or enclosed bottom parachute type design. These underwater air lift bags include commercial diving lift bags and professional lift bags.

Parachute type underwater lift bags are water drop shaped units. Generally, the open bottom underwater lift bags can be used at any depth for marine salvage or re-floatation objects from the seabed. Because the open bottom design makes the operation more safety. Therefore, this air lift bags is one kind of all-purpose inflatable salvage lift bag. Especially used for the scuba diving lift bags, marine salvage bags, lift bags salvage, floatation bags salvage, and float bags salvage.

The enclosed bottom parachute type lift bags have the same size as open bottom lift bags. But, there is one cover at the bottom. The user can open the cover according to the salvage project’s condition.


Features and Advantages

Made of heavy duty UV resistance PVC coated fabric
Overall assembly tested and proven at 5:1 safety factor by drop test
Double ply webbing slings with 7:1 safety factor
High Radio Frequency welding seam
Complete with all accessories, valve, inverter line, shackles, masterlink
High flow dump valves operated from bottom, easy to control buoyancy
Third party certificate is available upon request
CCS certificated to prove 5:1 safety factor

Parachute Underwater Lifting Bag Specificaitons


Lifting CapacityDimensions(m)Dump ValveAppr. Packed Size(m)Appr. Weight(kgs)
ModelkgslbsDiaHeightLengthWidthHeight
0BP-50L501100.31.1Yes0.40.150.152
OBP-100L1002200.61.3Yes0.450.150.155
OBP-250L2505500.81.7Yes0.540.20.27
OBP-500L500110012.1Yes0.60.230.2314
OBP-1100022001.22.3Yes0.80.40.324
OBP-2200044001.72.8Yes0.80.40.330
OBP-3300066001.83Yes1.20.40.335
OBP-55000110002.23.5Yes1.20.50.356
OBP-66000132002.33.6Yes1.20.60.560
OBP-88000176002.64Yes1.20.70.5100
OBP-1010000220002.74.3Yes1.30.60.5130
OBP-1515000330002.94.8Yes1.30.70.5180
OBP-2020000440003.15.6Yes1.30.70.6200
OBP-2525000551253.45.7Yes1.40.80.7230
OBP-3030000660003.86Yes1.410.8290
OBP-3535000770003.96.5Yes1.41.21.3320
OBP-50500001100004.67.5Yes1.51.41.3450

Underwater Lifting Bag Application

Deepwater salvage and flotation bag salvage

Commercial diving and military diving lift bags

Static infltable buoyancy support

Pipeline laying buoyancy floater

Subsea rigging lifting equipment

Marine salvage pontoon

Boat lift airbags
