Pneumatic Quick Release Disc Marine Towing Hook Ship Towing Equipment
Pneumatic Quick Release Disc Marine Towing Hook Ship Towing Equipment
Pneumatic Quick Release Disc Marine Towing Hook Ship Towing Equipment
Pneumatic Quick Release Disc Marine Towing Hook Ship Towing Equipment
Specifications
Place of Origin :
China
Brand Name :
Zhongyuan
Certification :
CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc.
Model Number :
Standard and Customized
MOQ :
1
Price :
As per quotation
Packaging Details :
Pallet or Customized
Delivery Time :
As per offer
Payment Terms :
TT, L/C, Etc.
Supply Ability :
Satisfy clients needs
SWL :
30t,50t,60t,80t,90t,100t
Material :
Mild Steel, C-Mn Steel
Usage :
Mooring and Towing, For Emergency Towing and Port Towing
Type :
Disc Type, Movement: Side Movement
Test :
Prototype Test, Break Load Test, Safe Working Load Test, Operation Test
Operation System :
Pneumatic Control, Remote Control, Manual Release
Surface treatment :
sandblasting to S2.5 + one layer of epoxy shop primer
Classification Certificates :
CCS, NK, BV, ABS, DNV-GL, LR, KR, RINA, IRS, RS, Etc
Description

Pneumatic Quick Release Disc Marine Towing Hook Ship Towing Equipment

Description

Marine towing hook is to pull the ship safely under severe conditions. It can release towing rope under conditions of slack or full safe working load to ensure the safety of the ship and personnel. It can be released locally or remotely from the wheel house by pulling the release wire or control button. Remote control systems release mechanism is either hydraulic or pneumatic.

We supply

  1. Quick Release Towing Hook
  2. Pneumatic/ Manual Release Disc Towing Hook
  3. Pneumatic Release Harbour Towing Hook
  4. Hydraulic Release Towing Hook
  5. Pneumatic / Manual Release Spring Towing Hook
  6. Single / Double / Triple / Quadruple Quick Release Mooring Hook
  7. Pelican Hook
  8. Buoy Type Quick Release Hook

Main Technical Specification:

1. SWL: 30t,50t,60t,80t,90t,100t

2.Material: Mild Steel, C-Mn Steel

3.Usage: Mooring and Towing, For Emergency Towing and Port Towing

4. Type: Disc Type, Movement: Side Movement

5. Test: Prototype Test, Break Load Test, Safe Working Load Test, Operation Test

6. Operation System: Pneumatic Control, Remote Control, Manual Release

7. Surface treatment: sandblasting to S2.5 + one layer of epoxy shop primer,

8. Classification Certificates:CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, Etc.

9. Can be Customized

Main Technical Parameters:

S.W.L. (ton) A B D H L N R
30 300 285 470 355 1278 180 60
50 395 360 470 405 1395 214 60
60 400 380 600 450 1628 220 80
80 410 400 600 466 1703 260 80
90,100 450 430 650 502.5 1915 328 88
NOTE: the technical parameters is only for reference

Pneumatic Quick Release Disc Marine Towing Hook Ship Towing Equipment

Pneumatic Quick Release Disc Marine Towing Hook Ship Towing Equipment

Pneumatic Quick Release Disc Marine Towing Hook Ship Towing Equipment

Drawing of Pneumatic Quick Release Disc Marine Towing Hook Ship Towing Equipment

Pneumatic Quick Release Disc Marine Towing Hook Ship Towing Equipment
