Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
China
Price :
Negotiable
Payment Terms :
Negotiable
Supply Ability :
100 ton/week
Delivery Time :
5-9 working days
Packaging Details :
Sea-worthy packing, ie wooden or steel tray with steel strip,etc
Description

Cold rolled steel coil is hot rolled steel coil as raw material, after pickling to remove the oxide skin for cold continuous rolling, the finished product is rolled hard coil, due to continuous cold deformation caused by cold hardening of rolled hard coil strength, hardness, toughness and plastic indexes decline, so the stamping performance will deteriorate, can only be used for simple deformation of the parts. Rolled rolls can be used as raw materials for hot-dip galvanising plants, because hot-dip galvanising units are equipped with annealing lines. Rolled hard coil weight is generally 6 ~ 13.5 tonnes, the inner diameter of the coil is 610mm/508mm.
General cold rolled plates and coils should be continuously annealed (CAPL unit) or annealed in the hood furnace to eliminate cold hardening and rolling stress, to achieve the mechanical properties specified in the corresponding standards.
Cold rolled steel plate surface quality, appearance, dimensional accuracy are better than hot rolled plate, and the thickness of its products right rolled thin to 0.18mm or so, so favoured by the majority of users. Cold rolled steel coil as a substrate for the deep processing of products, become high value-added products. Such as electro-galvanized, hot-dip galvanized, fingerprint-resistant electro-galvanized, colour-coated steel coils and vibration-damping composite steel, PVC laminated steel.
Big Discount JIS G3141 En10130 SPCC-1b DC01 CRC St12 & St13 & Ek4 Cold Rolled Low Carbon Cold Rolled Steel Coil

Advantages of cold rolled steel:
(1) Higher precision, cold rolled strip thickness difference of no more than 0.01~0.03mm.
(2) Thinner dimensions, cold rolled thinnest can be rolled 0.001mm steel strip; hot rolled can now be as thin as 0.78mm.
(3) Superior surface quality, cold rolled steel plate can even produce a mirror surface; while the surface of the hot rolled plate has iron oxide,pockmarks and other defects.
(4) Cold rolled plate can be adjusted according to user requirements of its school performance such as tensile strength and process performance such as stamping performance.

Big Discount JIS G3141 En10130 SPCC-1b DC01 CRC St12 & St13 & Ek4 Cold Rolled Low Carbon Cold Rolled Steel Coil

Specification Model

Deliverable Grade
Standard Q/BQB 408 JIS G3141 JFS A2001 EN 10130 DIN 1623 ASTM A1008 GB/T 5213 ISO 3574
Grade BLC SPCC JSC270C DC01 St12 CS CR1
BLD SPCD JSC270D DC03 RRSt13 DS CR2
BUSD SPCE JSC270E DC04 St14 DDS SC1 CR3
BUFD SPCF JSC270F DC05 EDDS SC2 CR4
BSUFD JSC260G DC06 SC3 CR5

Product Parameters

Standard Grade Chemical Composition of Cold Rolled Mild Steel(%) Mechanical properties of cold rolled steel
C Si Mn P S Yielding Strength
(MPa)
Tensile Strength
(MPa)
Elongation
(%)
JIS G3141 SPCC 0.15 max - 0.60 max 0.10 max 0.05 max
SPCD 0.12 max - 0.50 max 0.04 max 0.04 max ≤ 240 ≥ 270 ≥ 41
SPCE 0.10 max - 0.45 max 0.03 max 0.03 max ≤ 220 ≥ 270 ≥ 43
SPCF 0.08 max - 0.45 max 0.03 max 0.03 max ≤ 210 ≥ 270 ≥ 45
JIS G3141 Surface quality classification: B-finish; D-mirror finish
Heat treatment or state: A - annealed; S - tempered , 8 -1/8 hard, 4-1/4 hard, 2-1/2 hard, 1-hard
EN 10130 DC01 0.12 max - 0.60 max 0.045 max 0.045 max 140-280 270-410 ≥ 28
DC03 0.10 max - 0.45 max 0.035 max 0.035 max 140-240 270-370 ≥ 34
DC04 0.08 max - 0.40 max 0.030 max 0.030 max 140-210 270-350 ≥ 38
DC05 0.06 max - 0.35 max 0.025 max 0.025 max 140-180 270-330 ≥ 40
DC06 0.02 max - 0.25 max 0.020 max 0.020 max 120-170 270-330 ≥ 41
Surface type: A, B; Surface specification: b=special smooth, g=smooth, m=non-glossy, r=rude
Example of plate naming: EN 10130+A1-DC03-B-g where B is the surface type and g indicates that the surface specification is smooth

Big Discount JIS G3141 En10130 SPCC-1b DC01 CRC St12 & St13 & Ek4 Cold Rolled Low Carbon Cold Rolled Steel Coil
