Din 2391 St35 Precision Seamless Steel Pipe Anti Corrosion
Din 2391 St35 Precision Seamless Steel Pipe Anti Corrosion
Din 2391 St35 Precision Seamless Steel Pipe Anti Corrosion
Din 2391 St35 Precision Seamless Steel Pipe Anti Corrosion
Din 2391 St35 Precision Seamless Steel Pipe Anti Corrosion
Din 2391 St35 Precision Seamless Steel Pipe Anti Corrosion
Specifications
Brand Name :
GNEE
Model Number :
DIN 2391 ST35
Certification :
SGS
Place of Origin :
henan
MOQ :
1 Tons
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10000 Tons per Month
Delivery Time :
30 days
Packaging Details :
seaworthy export packing with fumigated wooden pallets or steel pallets
Product Name :
Seamless Precision Pipe
Grade :
DIN 2391 ST35
Standard :
DIN 2391
shape :
Round/Rectangle
Length :
10m-12m,12m or as customer's actual reques.
Package :
In Bulk, in Bunddle, in Water Proof plastic Wrap
Description

DIN 2391 ST35 pipe is a common low carbon steel containing chemical components such as carbon, silicon, manganese, phosphorus, and sulfur. The carbon content is between 0.17-0.23%, the silicon content is between 0.15-0.35%, and the manganese content is between 0.17-0.23%. Between 0.40-0.80%, the content of both phosphorus and sulfur does not exceed 0.035%.
ST35 precision pipe is a high-precision, high-brightness seamless steel pipe produced through cold drawing or cold rolling processes. The inner and outer diameter dimensions can be accurate to within 0.2mm. When bending and torsional strength are the same, the weight is lighter. ST35 high-gloss cold-rolled precision pipe is used to manufacture mechanical structures, hydraulic equipment, automobile parts, and steel sleeves.

Chemical composition of DIN 2391 St35 Seamless Precision Steel Tubes

Standard Grade C Mn Si S maximum P maximum
DIN2391 St35 ≤0.17 ≥0.4 ≤0.35 0.025 0.025

DIN 2391 ST35 Pipes Mechanical Behaviour

Cold drawn(Mandatory) Cold drawn(Soft) Cold Drawn and Stress Release Normalizing Anneal
BK1) BKW1) (BKS) (NBK)1) (GBK)1)
Grade Tensile Elongation Tensile Elongation Tensile Yield point Elongation Tensile Yield point Elongation Elongation Tensile
N/mm2 % N/mm2 % N/mm2 N/mm2 % N/mm2 N/mm2 % % N/mm2
St35 480 6 420 10 420 315 35 340~470 235 25 14 315

Standard Quality Specification Of DIN 2391 St35 Carbon Steel Seamless Pipes

Standard DIN 2391
Grade ST35
Size OD (4-190mm) x WT (0.5-15mm)
Outer Dimensions 4.0mm – 60.0mm
Wall Thickness 0.5mm – 8 mm
Length max 6000mm

Din 2391 St35 Precision Seamless Steel Pipe Anti Corrosion

GNEE group is not only committed to providing high-quality steel products, but also actively establishing close cooperative relationships with many companies. These include Baowu Group, Anyang Iron and Steel Group, Wuhan Iron and Steel, Shandong Iron and Steel, Jiugang Group, Shougang Group, Valin Iron and Steel and many other companies. These companies have excellent technical strength and rich experience in their respective fields, providing us with extensive support and help. By working together with these partners, we are able to drive innovation and development in the steel industry.

FAQ

Q:Are you trading company or manufacturer ?
A:We are professional manufacturer with 15 years' experience, and our company also is a very professional a trade company for steel products.We can also provide a wide range of steel products.

Q.Can your products be customized?
A.We can make most arades and specifications.meet your different requirement.

Q:How do your guarantee the quality?
A:Before mass production, there must be pre-production samples; before shipment, there must be final inspection.
