Specifications
Brand Name :
CQCY
Model Number :
Customized
Place of Origin :
China
MOQ :
1
Price :
US $680.00 - 800.00/ Set
Payment Terms :
T/T
Supply Ability :
1500 sets per year
Delivery Time :
6-8 weeks
Packaging Details :
Cardboard box/Wooden crate
applicable medium :
Air, Gas, Steam, Water
Nominal diameter :
DN15 ~ DN300
Flow characteristics :
Equal percentage, linear, quick-opening
Leakage class :
ANSI B16.104: IV,V,VI
Valve body material :
Cast steel, chromium-molybdenum steel, stainless steel
Nominal pressure :
PN10/16/25/40/63/100/160
Adjustable ratio :
50:1
Description
Chinese Wafer Butterfly Valve
Product Overview

Chinese wafer butterfly valves are compact, lightweight valves widely used in industrial piping systems. They feature a ductile iron body, stainless steel disc, and EPDM or NBR seat. The wafer design allows easy installation between flanges, making them a popular, cost-effective choice for on/off and throttling control of water, air, and mild chemicals in general industrial applications.

Technical Specifications
Parameter Specification
Type Wafer butterfly valve
Sizes DN40 to DN600 (1.5" to 24")
Pressure Rating PN10 / PN16
Body Material Ductile iron (GGG40 / GGG50)
Disc Material Stainless steel 304 / 316
Seat Material EPDM or NBR
Temperature Range -10 °C to +120 °C
Operation Lever or gearbox
Application Industry
  • Water supply and distribution
  • HVAC and air conditioning systems
  • Cooling water circuits
  • General industrial piping
  • Wastewater treatment
Common Problems & Solutions
  • Problem: Seat leakage after long service → Solution: Replace EPDM/NBR seat
  • Problem: Difficult operation on large sizes → Solution: Use gearbox instead of lever
  • Problem: Corrosion on disc → Solution: Choose 316 stainless steel disc
Replacement Models
  • Flanged butterfly valves
  • Chinese gate valves
  • Check valves
Why Buy From Us
  • Genuine Chinese factory product with test certificates
  • Competitive pricing for volume orders
  • Local technical support and fast response
  • Reliable delivery and spare parts availability
Stock & Delivery Time
  • Standard sizes and pressure ratings: in stock or 6–8 weeks
  • Special materials or large sizes: 6–10 weeks
RFQ Form

Please provide:

  • Size (DN or inch)
  • Pressure rating (PN10 / PN16)
  • Seat material (EPDM / NBR)
  • Operation type (lever / gearbox)
  • Quantity & delivery timeline
