Specifications
Brand Name :
Azbil
Model Number :
AVP100
MOQ :
1
Price :
US $1000.00 - 1200.00/ Set
Payment Terms :
T/T
Supply Ability :
500 sets per year
Delivery Time :
68 work days
Packaging Details :
Cardboard box
Input Signal :
4–20 mA DC
Air Supply Pressure :
130 to 700 kPa (≈ 1.3 to 7.0 bar)
Weight :
1.7 kg
Ambient Temperature :
–40 °C … +80 °C
Protection :
IP66
Description
Product Overview

The Azbil AVP100-HP is the high-performance variant of the AVP100 series, specifically engineered for large actuators and severe service applications. It delivers an industry-leading air capacity of 800 L/min while maintaining the same compact footprint and ultra-low bleed (0.1 L/min steady state). With HART 7, one-button auto-tuning, and advanced diagnostics via Valstaff software, the HP model ensures lightning-fast response and precise control even on high-thrust or high-volume actuators. Certified for explosion-proof and intrinsically safe areas, it is the preferred choice for refineries, petrochemical plants, and power generation facilities.

Key Features
  • 800 L/min Air Delivery: Fast stroking of large actuators.
  • Still Only 0.1 L/min Bleed: Energy efficient despite high flow.
  • One-Button Auto-Tuning: Automatic optimization for any actuator size.
  • HART 7 + Valstaff Diagnostics: Valve signature and performance monitoring.
  • Explosion-Proof Option: Ex d IIC T6 and intrinsically safe versions.
  • High Vibration Resistance: 10g tested.
  • Stainless Steel Option: 316SS housing for corrosive environments.
  • Fail-Safe / Fail-Freeze: Configurable safety behavior.
Technical Specifications
Parameter Specification
Model AVP100-HP (High Performance)
Input Signal 4–20 mA DC + HART 7
Air Supply 400–700 kPa (recommended)
Air Capacity 800 L/min (Sup) / 700 L/min (Exh)
Air Consumption ≤0.1 L/min (steady)
Stroke Linear: 10–150 mm; Rotary: up to 110°
Accuracy ±0.5% F.S.
Temperature -40°C to +80°C
Hazardous Area Ex d IIC T6, Ex ia IIC T4, FM Class I Div 1
Weight 2.8 kg (aluminum), 5.5 kg (stainless)
Applications
  • Refinery FCCU and coker valves
  • Power plant boiler feedwater and steam control
  • Large pipeline emergency shutdown valves
  • Petrochemical reactor charge pumps
  • LNG compressor anti-surge control
Frequently Asked Questions
What is the maximum air flow?

800 L/min — ideal for large or sticky actuators.

Is it still low-bleed?

Yes, only 0.1 L/min in steady state.

Can it replace older Yamatake positioners?

Yes, direct drop-in replacement for SVP, VP100, etc.

Is stainless steel available?

Yes, full 316SS housing option.

Contact Us

For severe-service solutions with the AVP100-HP:

Send your message to this supplier
Send Now
