Specifications
Packaging Details :
Cardboard box/Wooden crate
Operating Temperature :
-40°C to +85°C
Model Number :
3051
Payment Terms :
T/T
Ingress Protection :
IP66, Ip67
Delivery Time :
6~8 weeks
Process Connection :
1/4-18 NPT, 1/2-14 NPT, Flange Options
Output Signal :
4-20 mA DC / HART
Supply Ability :
2000 sets per year
Measurement Range :
Up to 4000 psia (275.8 bar)
Reference Accuracy :
Up to ±0.04% of Span
MOQ :
1
Price :
US $1700.00 - 2300.00/ Set
material :
316L Stainless Steel
Brand Name :
Rose-mount
Description
Product Overview

The Rose-mount 3051C Coplanar Pressure Transmitter is a highly accurate and reliable instrument for measuring differential, gauge, and absolute pressure. With up to ±0.04% of span accuracy and wide rangeability, it is widely used in process industries for critical pressure monitoring and control applications.

Technical Specifications
Parameter Specification
Measurement Types Differential, Gauge, Absolute
Accuracy Up to ±0.04% of span
Rangeability Up to 100:1
Output 4-20 mA with HART, FOUNDATION Fieldbus, PROFIBUS PA
Pressure Range Wide selection from 0-0.5 inH2O to 2000 psig
Materials 316L SST, Hastelloy C-276, etc.
Operating Temperature -40 to 185 °F (-40 to 85 °C)
Certifications SIL 2, Explosion-proof, etc.
Warranty 5-year limited warranty
Application Industry
  • Oil & gas production
  • Chemical and petrochemical
  • Power generation
  • Water and wastewater treatment
  • Pulp & paper processing
Common Problems & Solutions
  • Problem: Accuracy drift over time → Solution: High stability and 5-year warranty
  • Problem: Harsh environment exposure → Solution: Robust materials and certifications
  • Problem: Complex installation → Solution: Coplanar design for easy mounting
Replacement Models
  • Older Rose-mount 3051 series variants
  • Other pressure transmitters in the Rose-mount lineup
Why Buy From Us
  • Genuine Rose-mount 3051 with factory warranty
  • Competitive pricing
  • Local technical support and calibration service
  • Reliable spare parts availability
Stock & Delivery Time
  • Standard configurations: 6–8 weeks typical
  • Special materials or certifications: 6-12 weeks
RFQ Form

Please provide:

  • Measurement type (Differential/Gauge/Absolute)
  • Required pressure range
  • Output protocol (HART, Fieldbus, etc.)
  • Process conditions (temperature, media)
  • Quantity & target delivery date
