1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
Specifications
Warranty :
1 year
Classification :
Laboratory Heating Equipments
Customized support :
OEM, ODM
Brand Name :
shenlan
Model Number :
SK4-20-12TP
Place of Origin :
Henan, China
Size :
505*420*646mm
Material :
Quartz tube
Weight :
68kg
Voltage :
220
Rated temperature :
1200℃
Control accuracy :
±1℃
Furnace tube size :
40x205mm
Furnace tube material :
Quartz tube
Heating components :
Resistance wire
Thermocouple :
K-type thermocouple
Material carrier material :
Quartz crucible
Price :
$2,300.00/sets 1-4 sets
Description
1200C High Temperature Laboratory Electric Tubular Furnace with Double Quartz Zone
Series
1200℃
1400℃
1700℃
Model
SK4-20-12TP
SK4-35-12TP
SK6-35-12TP
SK4-35-14TP
SK6-35-14TP
SK4-35-17TP
SK6-35-17TP
Input power/
frequency

220/50HZ
Power
2KW
3KW
5KW
4KW
5KW
Furnace tube size（Φ*L）
40x205
mm
40x350
mm
60x350
mm
40x350
mm
60x350
mm
40x350
mm
60x350
mm
Maximum pressure
0.02mpa
Furnace tube material
Quartz tube
Corundum tube
Furnace tube load-bearing
5kg
Heating components
Resistance wire
Elema
Silicon molybdenum rod
Heating rate
Up to 20-25℃/min
Suggest 5 ℃/min
Rated temperature
1200℃
1400℃
1700℃
Working temperature
≤1100℃
≤1250℃
≤1550℃
Measuring range
≤1100℃
≤1300℃
≤1600℃
Control accuracy
±1℃
Thermocouple
K-type thermocouple
S-type thermocouple
B-type thermocouple
Material carrier material
Quartz crucible
Corundum crucible
Open mode
Split open type
Closed type
Net weight
68kg
72kg
74kg
117kg
121kg
160kg
162kg
Product dimensions (excluding furnace tubes)
505*420*646mm
650*420*665mm
650*420*665mm
790*565*765mm
790*565*765mm
790*565*765mm
790*565*765mm
