Custom Cut Duplex 2205/2507 Stainless Steel Plate for Mining Slurry Pipelines with Erosion-Corrosion Resistance
Custom Cut Duplex 2205/2507 Stainless Steel Plate for Mining Slurry Pipelines with Erosion-Corrosion Resistance
Custom Cut Duplex 2205/2507 Stainless Steel Plate for Mining Slurry Pipelines with Erosion-Corrosion Resistance
Custom Cut Duplex 2205/2507 Stainless Steel Plate for Mining Slurry Pipelines with Erosion-Corrosion Resistance
Specifications
Brand Name :
TISCO, ZPSS,BAOSTEEL,LISCO,JISCO
Model Number :
200 SERIES, 300 SERIES,400 SERIES, 904l,2205,2507 etc.
Certification :
SGS,ISO,CE,BIS
Place of Origin :
China
MOQ :
1 TON
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
2000Tons /Month
Delivery Time :
3~10 DAYS, Most of sizes are in stock
Packaging Details :
Export sea worthy packing with wooden pallet and well tied and protected, Or as to clients' requirements.
Product name :
Duplex 2205 2507 Stainless Steel Sheets
Standard :
ASTM A240/240M ; ASME SA-240/SA-240M; JIS G4305; DIN/BS/NF EN10028-7 ; ISO;GB/T 3280-2015
Technique :
Cold Rolled or Hot Rolled
Edge :
Mill Edge; Cut Edge
Samples :
Free to Supply
Grade :
2507,2205,201,304, 304L 316, 316L ,430, 410, 420, 316Ti, 321, 301, 309,309S, 310, 310S,etc.
Width*Length :
1000*2000;1219*2438;1219*3048; 1250*3000;1500*3000;1524*3048mm or per customized
Surface :
NO.1,2B,BA,8K,No.4,HL,SB,Embossed,Checkered, etc..
Thickness :
Cold Rolled: 0.3mm~6mm; Hot Rolled: 3mm~60mm
Trade Term :
FOB,CIF,EXW,CFR,DDU,DDP,DAP
Description
Custom Cut Duplex 2205/2507 Plate for Mining Slurry Pipelines and Chutes
Product Overview

Our custom-cut duplex 2205/2507 plates offer high strength, excellent erosion-corrosion resistance, and superior weldability for mining slurry handling equipment.

Problem Analysis

Mining slurries—characterized by acidic, chloride-rich, and abrasive properties—rapidly degrade 316L liners and mild steel chutes through synergistic erosion-corrosion mechanisms.

Engineering Solution

Duplex 2205/2507 alloys provide exceptional hardness, superior corrosion resistance, and twice the yield strength of conventional materials, significantly reducing equipment weight and operational downtime.

Technical Specifications
Parameter Details
Grade 2205, 2507
Thickness 5-60mm hot rolled
Size Custom width/length
Edge Cut edge, mill edge
Standard ASTM A240M, ASME SA-240
Applications
  • Slurry pipeline wear plates
  • Chute liners
  • Cyclone feed boxes
  • Thickened tailings tanks
Material Performance

The ferrite phase provides exceptional abrasion resistance while the austenite phase ensures superior toughness. High pitting resistance prevents undercutting of wear marks, extending service life.

Selection Guidelines

For highly acidic slurries (pH<3), choose 2507 grade. For neutral environments with high solids content, 2205 offers optimal cost-effectiveness. Request hardness testing (typically 28-32 HRC) for specific application validation.

Frequently Asked Questions
Can it be hardfaced?

Not needed; duplex alloys provide natural wear resistance without requiring additional hardfacing treatments.

What is the maximum plate size?

Custom sizes available up to 3000×12000 mm to accommodate various industrial requirements.

Suitable for wet sand applications?

Excellent performance in wet sand environments, significantly outperforming AR400 steel in both corrosion resistance and durability.
