Specifications
Brand Name :
Shenghong
Model Number :
SH160912-11
Certification :
CE ISO
Place of Origin :
China, Jiangsu
MOQ :
1 sets
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
30 SETS / year
Delivery Time :
40 days after payment
Packaging Details :
Container
Controls :
Mitsubishi transducers, Schneider Electric, PLC
Roller :
Antirust Treatment
Yield Stress :
200-350
Certificate :
CE, ISO9001:2008,
Yield strength :
230-350
Roller material :
45#Steel with chrome plated
Description

Double Press Glazed Tile Roll Forming Machine With Transmission Chain

Main technical features

  1. Adopt independence guide post supporting wall plate and inside transmission chain, the rollers are treated with ionitriding and polishing.
  2. Setup the sheet pre-cutting equipment to avoid waste of raw material.
  3. Procedure control and encoder measuring the length, it will automatically to length.
  4. Adopt procedure control stacher which will automatically stack, take count and move out the procducts.

Techincs flow

Decoiling---- guiding and feeding--- roll forming--- cut to length--- run out table

Specification

Item Parameter
Model Single Press Double Press
Material Type Cloured steel sheet
Thickness 0.4-0.8
Yield strength 230-350
Max.forming speed 4-5 10-12
Roller material 45#Steel with chrome plated
Roller driven type Chain transmission
Controller PLC
Operation Touch screen+button
Hydraulic system pressure 13 16
Hydraulic station motor power 7.5 9
Main motor power 4 11
Total power 11.5 20
Total weight About 10000

Producing process sketch of glazed steel tile roll forming machine:


Double Press Cold Roll Forming Machine Easy Operation With Transmission Chain

Machine photo
Double Press Cold Roll Forming Machine Easy Operation With Transmission Chain
