Carbon Steel Sheet Metal Shear Blades Hot Roll Cross Cutting
Carbon Steel Sheet Metal Shear Blades Hot Roll Cross Cutting
Carbon Steel Sheet Metal Shear Blades Hot Roll Cross Cutting
Carbon Steel Sheet Metal Shear Blades Hot Roll Cross Cutting
Specifications
Brand Name :
SENDA
Model Number :
SD002
Certification :
ISO9001
Place of Origin :
China
MOQ :
1pcs
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Delivery Time :
30-35days
Packaging Details :
anti-rust oil in plastic bag and Packed in strong plywood cases
Name :
Guillotine shear blade
Other blade :
metal shear blade,cross cutting blade,straight cutting blade
Material :
HMY
Size :
Max 6000mm Length
Hardness :
range: HRC51-65
Application :
Cut to length line,slitting lines
Description

carbon steel coil guillotine shear blade for cross cutting machine

Senda carbon steel coil guillotine shear blade are mainly applied to guillotine shears, flying shears and cut to length lines. SENDA have new HMY material , perfectly shear 3-16mm high strength steel coils at the same time without edge broken. with this material we can get more satisfaction from our customers. welcome your inquiry.

Brand Senda
Country of Origin China
Material HMY
Size: Max 6000mm Length
Size: Customized
Hardness 51-65HRC
Application Cut to length line, slitting line

Advantages of guillotine shear blade for cross cutting machine:

1. Senda Guillotine shear blades can shear metal materials generally reach 9000~15,000tons for one time sharpening to ensure the productions and life-time without edge broken.

2. New HMY material , perfectly shear 3-16mm high strength steel coils at the same time.

3. Liquid nitrogen -196degree cold treatment ensure the hardness and toughness

4. vertical pit furnace ensure the heat-treatment.

Application of the carbon steel coil guillotine shear blade:

1. Normally for hot rolling: 3~12mm carbon steel coils etc.

2. Normally for cold rolling: 0.2mm~3.2mm carbon steel plates, galvanized plates etc.

3. popular size:

dividing shear 3500×170×100； 3500×150×100； 3200×180×80；
double side shears TOP 2080×170×100, 2200×170×100
double side shears BOTTOM 2075×160×70, 2200×150×100
shear blade 2600×220×70； 3400×220×70； 3500×200×60 ； 2100×162×65；
2100×150×65； 2650×150×40； 2800×205×100； 2800×150×100

Carbon Steel Sheet Metal Shear Blades Hot Roll Cross Cutting

Carbon Steel Sheet Metal Shear Blades Hot Roll Cross Cutting

Hot Strip Mill Knives
Straight Crop Shear Knives
Curved Crop Shear Knives with or without Vector
Sample/Inspection shear knives

Aluminium Mills
Slab Shear knives
Crop Shear Knives

CSP Mills
Pendulum Shear Knives in High nickel Alloy or Hot Work Tool steel
High Speed exit drum shear knives

Steckel Mills
Rotary Drum Shear Knives

Senda starting from 1998, focus on the quality of products and provide better service. Now we have over 100 workers, CNC lathes, High precision internal and external circular grinding machines, heat-treatment furnaces grinding machines and inspection machines.
