Single Core Armoured Electrical Cable 1kV Copper Conductor PVC Insulated Stainless Steel Tape Armored Cable

Power Your Projects with Shenghua Cable’s 4-Core 1KV Armoured Solution: Where Durability Meets Sustainability​​

In an era demanding resilient and eco-conscious infrastructure, ​​Shanghai Shenghua Cable (Group) Co., Ltd.​​ emerges as a global leader in advanced electrical solutions. Our ​​4-Core 1KV Steel Wire Armoured (SWA) Cable​​ combines military-grade protection with environmental innovation—engineered for critical power transmission and distribution networks worldwide.

​​Unmatched Engineering for Extreme Conditions​​

1. ​​Triple-Layer Defense System​​

   • ​​Conductor​​: Class 1/2 copper per IEC 60228, ensuring optimal conductivity and mechanical flexibility


   • ​​Insulation​​: Cross-linked polyethylene (XLPE) rated for 90°C normal operation, 130°C emergency overload, and 250°C short-circuit survival (5s)


   • ​​Armour​​: Steel wire/tape or lightweight aluminium tape options for crush resistance and EMI shielding


   • ​​Eco-Armor​​: PVC, PE, or ​​LSOH (Low Smoke Zero Halogen) sheath​​—reducing toxic emissions during fires while resisting UV, chemicals, and stress cracking



2. ​​Certified Global Compliance​​
   Adhering to:

   • International: ​​IEC 60502-2, IEC 60228​​
   • China: ​​GB/T 12706.2-2008​​
   • On-demand certifications: CE, RoHS, KEMA, BS6387耐火等级 (950°C/3h fire resistance)



​​Performance Beyond Specifications​​

• ​​Bending Radius​​: Compact 12× cable diameter (multi-core armoured)—ideal for tight conduits and underground trenches


• ​​Current Capacity​​: Up to ​​575A in soil​​ (4×400mm² cores), minimizing energy loss


• ​​Lifespan​​: XLPE anti-aging properties extend service life to ​​40+ years​​, outperforming standard PVC cables by 300%



​​Applications Redefining Safety & Efficiency​​

Deployed across high-stakes environments:

• ​​Industrial Plants​​: Withstands chemical corrosion in petrochemical/cement facilities


• ​​Renewable Energy​​: UV-resistant LSOH sheaths for solar farms and wind turbine grids


• ​​Smart Cities​​: Powers underground metro systems and high-rise buildings with flame-retardant reliability



​​Why Global Clients Trust Shenghua Cable?​​

• ​​Manufacturing Prowess​​: #2 in China’s cable industry with ​​6 production bases​​ and ​​100KM/week output​​


• ​​Eco-Innovation​​: LSOH sheaths align with EU RoHS/REACH, reducing carbon footprint





• ​​Service Guarantee​​:
  • ​​12-month warranty​​ backed by PICC insurance


  • ​​24/7 global support​​: 72-hour problem resolution worldwide


  • ​​Moisture-sealed packaging​​: Wooden reels with BOPP tape—ensuring corrosion-free deliver

Construction

Conductor : Annealed Copper Conductor as per IEC 60228
≤6mm2 solid (class 1) or stranded (class 2)
＞6mm2 stranded (class 2)
Flexible conductor(class 5) optional.
Insulation : XLPE(cross-linked polyethylene) rated at 75℃
Metallic Screen optional : Copper tape or copper wires braiding optional
Armored optional: :Aluminum wire or stainless steel tape for single core cable, Steel wire or steel tape for multi core cable
Sheath : PVC or FR-PVC type ST2 to IEC 60502, black or red or customization


Applications

This product is applicable to the fixed routing in the power distribution network or the industrial equipment with power frequency rated voltage of 1kV and below.
For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces.
Application Standard: IEC/BS/UL/GB Standards

Standards

International: IEC 60502, IEC 60228, (IEC 60332-3 for FR-type only)
China: GB/T 12706, (GB/T 18380-3 for FR-type only)
Other standards such as BS,DIN and ICEA upon request

Technical data

Rated voltage:0.6/1kV Low Voltage
Maximum Conductor Temperature: under normal (75 ℃), emergency (130℃) or short circuit no more than 5 s (160℃) conditions.
Min. Ambient Temp. 0 OC, after installation and only when cable is in a fixed position
Min. Bending Radius: 20 x cable O.D for single core without armor
15 x cable O.D for multi core without armor
15 x cable O.D for single core with armor
12 x cable O.D for multi core with armor

Certificates

ISO,CE, KEMA ,IEC, RoHS, CCC, P3C and more others at request
