Specifications
Place of Origin :
China
Certification :
CE ISO certification
MOQ :
1
Packaging Details :
The wooden case,Tin trunk ,Other seaworthy packing
Delivery Time :
45-60 days
Payment Terms :
T/T,L/C,,Western Union
Supply Ability :
45-60 days
Power_Requirement :
AC 220V/380V, 50/60Hz
Pallet_Change_Time :
6 seconds
Maximum Tapping Diameter :
Φ20
Warranty :
1 Year
Spindle_Speed :
10,000 RPM
Rapid_Traverse_Rate :
60 m/min
Suitable For :
various box parts rough finishing
Main Motor Power :
15/18.5kw
Processing Capabilities :
high precision and high efficiency
Table Surface Type :
T-slot
Control System :
GSK SIEMENS FANUC
Table Graduation :
1°*360
Table_Size :
500mm x 500mm
Max_Load_Capacity :
500kg
Tool_Capacity :
30 tools
Description

HMC series of machine tools adopts an advanced T-shaped integral bed structure, gantry-type column, and a front-hung box layout. It features strong rigidity and good precision retention. The entire machine tool is professionally designed and manufactured with the main focus on low center of gravity, anti-twist, anti-rust, heavy cutting, and high material removal efficiency.

Description

■ Machine Structure

HMC series
of machine tools adopts an advanced T-shaped integral bed structure, gantry-type column, and a front-hung box layout. It features strong rigidity and good precision retention. The entire machine tool is professionally designed and manufactured with the main focus on low center of gravity, anti-twist, anti-rust, heavy cutting, and high material removal efficiency.

By applying finite element analysis (FEM), the shape and position of the reinforcing ribs of the castings are optimized to achieve the best bed strength. Additionally, the base and Z-axis column have been specially reinforced to make the bed structure more suitable for heavy cutting and increase the tool life.of the castings, making the bed strength optimal. Additionally, special reinforcement structures are applied to the Y-axis base and Y-axis column to make the bed structure more suitable for heavy cutting and increase the tool life.

HMC1000 CNC Horizontal Machining Center High Precision 220V 380V 10000RPM



Specifications

Machine Type HMC1000
工作台尺寸Workbench size 1000x1000 mm
Workbench T-slot (number - size * pitch) 7-22x130 mm
Max. load capacity of the workbench 2100KG
X轴行程 X-axis travel distance 1600mm
Y轴行程 Y-axis travel distance 1000mm
Z轴行程 Z-axis travel distance 1100mm
主轴中心线至工作台面距离
Distance from the centerline of the main shaft to the worktable surface
20-1020mm
主轴端面到工作台中心距离
Distance from the spindle face to
the center of the worktable
250-1350 mm
导轨形式 Guide rail form Precision Grade P roller-type linear guide
X,Y,Z快移速度 X,Y,Z fast movement speed 24m/min
X轴电机最大转矩 X axis Max. torque of motor 69N.m
Y轴电机最大转矩 Y axis Max. torque of motor 85.2N.m
Z轴电机最大转矩 Z axis Max. torque of motor 85.2N.m
主轴最高转速 Max. spindle speed 6000 rpm
主轴锥孔 Spindle taper hole BT50
主轴电机功率 Spindle motor power 15/18 KW
刀库容量 Tool magazine capacity Disc-Type 30Tools
刀具最大重量 Max. weight of cutting tools 8KG(BT40) / 15KG(BT50)
气源压力 Air source pressure 0.5-0.8 MPa
定位精度 Positioning accuracy 0.012mm
重复定位精度 Repeatability positioning accuracy 0.008mm
B轴定位精度 Positioning accuracy of B-axis 10"
B轴重复定位精度 Repeatabilitypositioning accuracy of B-axis 6"
Machine size (L x W x H) 5600x4300x3100mm
Standard weight 21000KG



Machine Tool Configuration

CNC system: FANUC, Siemens,SYNTEC, KND,Mitsubishi

HMC1000 CNC Horizontal Machining Center High Precision 220V 380V 10000RPMHMC1000 CNC Horizontal Machining Center High Precision 220V 380V 10000RPM
High-quality spindle, imported bearings



HMC1000 CNC Horizontal Machining Center High Precision 220V 380V 10000RPM
THK, PMI, HIWIN, HTPM 45,55 Precision Grade P roller-type linear guide

HMC1000 CNC Horizontal Machining Center High Precision 220V 380V 10000RPM
Standard equipped with a lift-free turntable, continuous positioning and indexing can reach 0.001°. The entire series adopts a slider direct connection structure, featuring high rigidity and high precision.

HMC1000 CNC Horizontal Machining Center High Precision 220V 380V 10000RPM
The double lead precision worm gear and worm achieve zero clearance transmission and a maintenance-free lifespan of 20,000 hours. It also features a large transmission ratio, smooth transmission, and self-locking properties, making it particularly suitable for milling operations.
HMC1000 CNC Horizontal Machining Center High Precision 220V 380V 10000RPM
Imported P4 grade precision turntable bearings are selected, featuring three rows of rollers that respectively provide axial and radial support. This results in a large clamping torque on the worktable surface and a strong anti-overturning torque.

HMC1000 CNC Horizontal Machining Center High Precision 220V 380V 10000RPM
Standard equipped with chain-typechip conveyor and small iron chip cart.
HMC1000 CNC Horizontal Machining Center High Precision 220V 380V 10000RPM

High-quality disc-type /Umbrella-type ATC Tool magazine

HMC1000 CNC Horizontal Machining Center High Precision 220V 380V 10000RPM
