Specifications
Place of Origin :
China
Certification :
CE ISO certification
MOQ :
1
Packaging Details :
The wooden case,Tin trunk ,Other seaworthy packing
Delivery Time :
45-60 days
Payment Terms :
T/T,L/C,,Western Union
Supply Ability :
45-60 days
Type :
Gantry
Function :
Drilling and Milling
Application :
Metalworking
Table Size :
Large
Power Source :
Electric
Number Of Axes :
3
Spindle Power :
High
Control System :
CNC
Accuracy :
High
Automation :
Fully Automated
Max. Load Capacity :
Heavy
Description

GNC series CNC gantry boring and milling machine, inheriting the strong rigidity and high stability of gantry machines, is equipped with high-rigidity spindles, advanced CNC systems and other components. It can efficiently perform drilling, tapping and milling surface processing on large workpieces, large plates, wind turbine flanges, discs, rings and other workpieces

Description

Customers can achieve efficient drilling, tapping and milling of large workpieces with relatively low equipment cost investment. The fully CNC operation without programming improves processing quality and efficiency, and reduces labor costs. GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated
Standard equipped with a water filtration system at the center of the spindle, suitable for U-drill processing. GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated



Specifications

Machine Model GNC1020 GNC1616 GNC2016 GNC2020 GNC2525 GNC3020 GNC4025
Workbench size 2000x1000mm 1600x1600mm 2000x1600mm 2000x2000mm 2500x2500mm 3000x2000mm 4000x2500mm
最大钻孔直径Max. drilling diameter Φ50 Φ75 Φ75 Φ90 Φ90 Φ90 Φ90
最大攻丝直径Max. tapping diameter M24 M32 M32 M36 M36 M36 M36
Distance from the spindleface to the worktable surface 160-760mm 200-800mm
主轴锥孔 Spindle taper hole BT40 BT50 (with a center water outlet function)
主轴电机功率 Spindle motor powe 7.5/11 KW 11/15 KW 15/22 KW
主轴最高转速 Max. spindle speed 3000rpm
X-axis travel distance 2000mm 1600mm 2000mm 2000mm 2500mm 3000mm 4000mm
Y-axis travel distance 1000mm 1600mm 1600mm 2000mm 2500mm 2000mm 2500mm
Z-axis travel distance 600mm 600mm 600mm 600mm 600mm 600mm 600mm
X,Y,Z快移速度 X,Y,Z fast movement speed 10/15/15 m/min 10/12/12 m/min
XYZ轴重复定位精度 Spindle taper hole 0.015/2000mm 0.02/2000mm
刀库容量 Tool magazine capacity 直排式刀库 Straight-line tool magazine
(选配Optional configuration)圆盘式/24把 Disc-Type 24Tools
刀具最大重量 Max. weight of cutting tools 8KG(BT40) / 15KG(BT50)
Machine size (L x W x H) cm 350x180x220 300x380x220 350x380x220 350x420x220 400x460x220 4500x420x220 550x460x220
Standard weight 9 T 13 T 16 T 25 T 28 T 28 T 35 T


Machine Tool Configuration

CNC system: KND,SYNTEC,

GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated
High-quality spindle, imported bearings



GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated
PMI, HIWIN, HTPM 35,45 Precision Grade P roller-type linear guide

GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated
PMI, HIWIN C3 grade precision ground ball screw

GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated
High-quality tool clamping cylinder
GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated
NSK, SKF, FAG P4 grade imported angular contactpaired bearings


GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated
Precision high-rigidity coupling




GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated
Imported high-torque synchronous belts


GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated
High-quality disc-type /Umbrella-type ATC Tool magazine


GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated

Standard equipped with chain-typechip conveyor and small iron chip cart.

GNC Series Gantry CNC Mill Drill Machine With BT40 BT50 Spindle Taper Fully Automated

About Us

Shanjmc is a leader in precision machinery manufacturing, dedicated to advancing industrial standards with our innovative solutions. Our PSG/GM Series precision surface grinding machines are crafted from HT300 high-grade material, ensuring high strength, resistance to deformation, and excellent shock absorption. We prioritize quality and performance, equipping our machines with advanced features like hydrostatic spindles and ultra-precision linear guides from renowned brands such as Japanese THK, German INA, and Taiwan PMI. Our scalable designs accommodate various workbench sizes and load capacities, making them ideal for diverse industrial applications. At Shanjmc, we are committed to providing reliable, high-performance equipment that meets the growing demands of grinding machine manufacturers. Our machines are available for bulk ordering, offering long-term value and stable precision over extended use. Whether you're looking to upgrade your equipment or expand your operations, Shanjmc's precision grinding machines are a strategic investment for sustained industrial success.

Contact Shanjmc today to upgrade your industrial operations with our precision surface grinding machine. Lets achieve unmatched precision and performance!

FAQ

Q:Who are we?

A:We are Hubei Shangjie Precision Machinery Manufacturing Co., Ltd., a leading manufacturer of precision surface grinding machines designed for industrial applications. Our PSG/GM Series machines are renowned for their high rigidity and precision, crafted from HT300 high-grade material to ensure stable performance over long-term use.

Q:How can we guarantee quality?

A:We guarantee quality through rigorous manufacturing processes and the use of premium materials like HT300 high-grade castings. Our machines undergo vibration stress relief and secondary tempering processes to eliminate internal stress, ensuring consistent precision and durability.

Q:What can you buy from us?

A:You can purchase a wide range of industrial equipment from us, including precision surface grinding machines, CNC turning centers, machining centers, and tailor-made automation solutions. Our products are designed to meet the demanding needs of professional and bulk ordering applications.

Q:Why should you buy from us not from other suppliers?

A:Choosing Shanjmc means investing in unmatched precision and rigidity. Our machines feature advanced components like hydrostatic spindles and ultra-precision linear guides, ensuring high efficiency and long service life. We offer scalable designs to adapt to future demands, providing long-term value and reliability.

Q:What services can we provide?

A:We offer comprehensive services including product customization, bulk ordering options, and tailor-made automation solutions. Our team is dedicated to enhancing your production efficiency and expanding your operational capabilities.

Q:Can I customize this product for my business?

A:Yes, our precision surface grinding machines can be customized to meet your specific business needs. We offer scalable designs that accommodate various workbench sizes and load capacities, ensuring that our machines fit seamlessly into your production environment.

Q:Do you offer wholesale pricing?

A:Absolutely, we provide competitive wholesale pricing for bulk orders. Our precision surface grinding machines are ideal for grinding machine manufacturers looking to expand their c
