Specifications
Place of Origin :
China
Certification :
CE ISO certification
MOQ :
1
Packaging Details :
The wooden case,Tin trunk ,Other seaworthy packing
Delivery Time :
45-60 days
Payment Terms :
T/T,L/C,,Western Union
Supply Ability :
45-60 days
Table Size :
600mm x 400mm
Weight :
6,500kg
Spindle Speed :
10,000 RPM
Type :
Vertical Machining Center
Power Supply :
3 Phase, 220V/380V/415V
Spindle Taper :
BT40
Controller :
Fanuc/Mitsubishi/Siemens
Max Load Capacity :
300kg
Warranty :
1 year
Number Of Axes :
3
Tool Capacity :
24
Rapid Traverse Rate :
30m/min
Dimensions :
2,500mm x 2,000mm x 2,500mm
Description

VS series is a heavy-duty vertical machining center. All models adopt 6 sliders on the X-axis, 4 roller linear guides with 8 sliders on the Y-axis, and the Z-axis column is equipped with an increased installation foot span to make the base wider and provide a solid foundation for the machine tool's processing performance.

The VS130 is a robust vertical machining center designed for heavy-duty industrial applications. It features a low center of gravity, anti-distortion structure, and high material removal rate, ensuring precision and durability. Ideal for manufacturers seeking efficient and reliable machining solutions.

Description

Machine Type VMC1160
工作台尺寸Workbench size 1300x600 mm
Workbench T-slot (number - size * pitch) 5-18x100 mm
Max. load capacity of the workbench 800KG
X轴行程 X-axis travel distance 1110mm
Y轴行程 Y-axis travel distance 610mm
Z轴行程 Z-axis travel distance 600mm
Distance from the center of spindleto the guide rail of the column 660mm
Distance from the spindle face tothe worktable surface 120-720 mm
导轨形式 Guide rail form Precision Grade P roller-type linear guide
X,Y,Z快移速度 X,Y,Z fast movement speed 30m/min
X轴电机最大转矩 X axis Max. torque of motor 55.8N.m
Y轴电机最大转矩 Y axis Max. torque of motor 55.8N.m
Z轴电机最大转矩 Z axis Max. torque of motor 69N.m
主轴最高转速 Max. spindle speed 8000/12000 rpm
主轴锥孔 Spindle taper hole BT40
主轴电机功率 Spindle motor power 11/15 KW
刀库容量 Tool magazine capacity Disc-Type 24Tools
刀具最大重量 Max. weight of cutting tools 8Kg
气源压力 Air source pressure 0.5-0.8 MPa
Machine size (L x W x H) 2450x2180x2550mm
Standard weight 8000KG


Specifications

Machine Type VS120
工作台尺寸Workbench size 1300x600 mm
Workbench T-slot (number - size * pitch) 5-18x100 mm
Max. load capacity of the workbench 1000KG
X轴行程 X-axis travel distance 1210mm
Y轴行程 Y-axis travel distance 610mm
Z轴行程 Z-axis travel distance 630mm
Distance from the center of spindleto the guide rail of the column 675mm
Distance from the spindle face tothe worktable surface 130-760 mm
导轨形式 Guide rail form Precision Grade P roller-type linear guide
X,Y,Z快移速度 X,Y,Z fast movement speed 30m/min
X轴电机最大转矩 X axis Max. torque of motor 55.8N.m
Y轴电机最大转矩 Y axis Max. torque of motor 55.8N.m
Z轴电机最大转矩 Z axis Max. torque of motor 69N.m
主轴最高转速 Max. spindle speed 8000/12000 rpm
主轴锥孔 Spindle taper hole BT40 (BT50 Optional)
主轴电机功率 Spindle motor power 11/15 KW (※15/18 KW)
刀库容量 Tool magazine capacity Disc-Type 24Tools
刀具最大重量 Max. weight of cutting tools 8KG(BT40) / 15KG(BT50)
气源压力 Air source pressure 0.5-0.8 MPa
Machine size (L x W x H) 2520x2150x2620mm
Standard weight 9500KG



Machine Tool Configuration

CNC system: FANUC, Siemens,SYNTEC, KND,Mitsubishi

VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPMVS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM
High-quality spindle, imported bearings



VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM
THK, PMI, HIWIN, HTPM 45,55 Precision Grade P roller-type linear guide

VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM
THK, PMI, HIWIN C3 grade Ø50 precision ground ball screw

VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM
High-quality tool clamping cylinder
VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM
NSK, SKF, FAG P4 grade imported angular contactpaired bearings


VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM
Precision high-rigidity coupling




VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM
Imported high-torque synchronous belts


VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM
High-quality disc-type /Umbrella-type ATC Tool magazine


VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM

Standard equipped with chain-typechip conveyor and small iron chip cart.

VS1160 Heavy Duty Vertical Machining Center With BT40 Spindle Taper Hole 8000 12000RPM


Company advantages

Our company has passed the quality system certification. We have independent design and R&D capabilities. Our company is equipped with large gantry machining centers, five-axis machining centers, vertical machining centers and other large-scale processing equipment. We have a dedicated after-sales service team, committed to providing customers with convenient and efficient after-sales service.

Product advantages

Our machine tools use HT300 high-grade castings with an ergonomic design. We select imported functional components, ensuring long-term dimensional stability without deformation. We have independent design and R&D capabilities, completing all processes from casting to sheet metal fabrication in-house, allowing for quality control.

Application scenarios

It is applicable to mechanical processing fields such as automotive manufacturing, aerospace, and shipbuilding

FAQ:

1,Q:Manufacturer or trading company? Where is the company located?

A:We are a professional manufacturer of CNC lathes, located in Shiyan City, Hubei Province.

2,Q:How long have you been involved in this market?

A:We have been engaged in the auto parts industry for 10years

3,Q:Can you provide a product catalog?

A:Contact our business manager, we will send the product catalog you need to your mailbox

4,Q:About the terms and conditions of payment.

A:When you quote, we wil confim with you the trading method,FOB,CIF CNF, o other methods. in mass production we usull pay 30% advance payment frst then seethe balance of the bill of lading.Most of the payment methods are T/T, of course,L/C is also acceptable.

5,Q:Product after-sales service scope and service period

A:We offer a one-year warranty and 24-hour lifetime technical support
