Specifications
Place of Origin :
SHAANXI,XIAN
Brand Name :
SHACMAN
MOQ :
1
Price :
Negotiable
Delivery Time :
35-55days
Color :
Blue, Green, Yellow, White
Application :
Construction/Warehouse/Terminals/Logistics/Rescue
Rated Lifting Moment :
360kN.m
Max. Lifting Height :
10.77-23.8M
UNIQUE SELLING POINT :
High operating efficiency/Fully hydraulic system
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Core Components :
Pressure Vessel, Motor, Bearing, Gear, Pump, Gearbox, Engine
Weight (KG) :
2400 kg
Max. Speed :
90km/h
Description
SHACMAN Folding Arm Crane Trucks
Available Configurations
Truck Chassis
  • Primary brand: SHACMAN
  • Other available brands upon request: Dongfeng, FAW, FOTON, ISUZU, SINOTRUK HOWO, BEIBEN, JAC, JMC, and more
Drive Type
4×2 4×4 6×4 6×6 8×4
Emission Standards
Euro II Euro III Euro V Euro VI
Crane Brands
Leading crane manufacturers including XCMG, SANY, Palfinger, UNIC, and others
Lifting Capacity
Available in capacities from 2 tons to 20 tons
2T 3.2T 4T 5T 6.3T 8T 10T 12T 14T 16T 18T 20T
Crane Arm Design
  • Straight Arm: Economical and suitable for standard lifting tasks
  • Folding Arm (Knuckle Boom): Compact, flexible, and generally priced higher for the same lifting capacity
Cargo Box Dimensions
Fully customizable to meet client needs, with technical recommendations available from our expert team
Municipal Engineering Truck Crane Manipulator Pickup Truck Crane Hoist 10.77-23.8M Crane Truck with Flatbed
Technical Specifications
Specification Model 1 Model 2 Model 3 Model 4 Model 5 Model 6 Model 7 Model 8
Max. Lifting Weight 9400kg 15000kg 20000kg 35000kg 45000kg 60000kg 72000kg 92000kg
Max. Lifting Torque 228kN*m 300kN*m 400kN*m 750kN*m 900kN*m 1200kN*m 3600kN*m 4500kN*m
Max. Working Radius 18.2m K108 18.5m 20.45m 20.25m 22.2m 22m 23.8m
Luffing Range 0°~86° 0°~80° 0°~80° 0°~80° 0°~77° 0°~80° 0°~75° 0°~75°
Slewing Angle 360° 360° 360° 360° 360° 360° 360° 360°
Max. Operating Pressure 30MPa 33MPa 33MPa 33MPa 34MPa 32MPa 33MPa 30MPa
Oil Flow Volume 55L/min 64L/min 60L/min 80-100L/min 80-100L/min 108L/min 60L/min 108L/min
Oil Tank Capacity 90L 90L 90L 200L 240L 240L 240L 270L
Crane Weight 3500kg 4300kg 5900kg 8400kg 10000kg 18000kg 20000kg 22000kg
Municipal Engineering Truck Crane Manipulator Pickup Truck Crane Hoist 10.77-23.8M Crane Truck with Flatbed
Henan Senyao Heavy Truck International Trade Co., Ltd.
As a globally authorized export enterprise for Shaanxi Automobile, we specialize in the integrated supply of heavy-duty trucks, specialized vehicles, and construction machinery.
Upholding our core principle of "mutual benefit, integrity, and win-win cooperation," we have established a comprehensive sales network across Central Asia, Africa, and Central and South America, supported by a strong brand reputation and a streamlined in-house procurement and supply system.
With an annual export capacity exceeding 3,000 units, Senyao has gained recognition worldwide for delivering reliable, military-grade products and professional export services. Our commitment to quality, performance, and customer satisfaction drives us to build lasting and productive partnerships globally.
We look forward to collaborating with you for long-term success.
