SHACMAN fire truck is equipped with foam tank, proportional mixing system and water pump, which can accurately mix water with foam extinguishing agent to generate a large amount of foam, effectively cover the fire source, isolate oxygen and extinguish the flame.Fire engines are widely used in petrochemical plants, airports, oil depots and gas stations, large traffic tunnels and dangerous goods warehouses. 1. Large capacity liquid tank 2. Powerful fire pump and gun 3. Advanced foam system 4. Durable low maintenance structure 5. Reliable Shaanxi automobile chassis 6. Humanized operation design 7. Safety and operational assistance 8. High customization flexibility

Truck Brand	SHACMAN L3000 Series Foam Fire Truck
Chassis	Driving Style	Left hand drive or right hand drive
	Driving Type	4x2 or 6x4, 8x4
	Frame	850×300(8+7)mm
	Wheelbase	5000mm
	Vehicle Speed Ratio	13T MAN double speed reduction bridge-5.262
	Emission Standard	EURO 3
	Suspension	Front and rear multi-leaf springs
Fire Extinguishing Agent Tank	Tank capacity	Water tank: 10m³, Foam tank: 1m³
	Tank material	300L aluminum alloy
Fire Pump	Rate of flow	60L/s
	Pressure	1.0MPa
Vacuum Pump	Working form	Piston
	Water diversion time	≤35s
	Water absorption depth	≥7m
	Maximum working pressure	≥85Kpa
Pipeline System	Water suction line	DN150 inlet
	Outlet pipeline	One DN100 outlet fire cannon pipe is set on the roof.
		One DN80 and one DN65 outlet are set on both sides of the pump room.
Fire Cannon	Brand	WESTE, PL8/48W fire cannon
	Rate of flow	1.0MPa
	Work radiu	Water≥ 70m, foam≥ 65m

1.Professional export packaging: Weather-proof and secure. 2.Multiple shipping methods: RORO, container, or bulk vessel. 3. Worldwide deliver: Experience in shipping to 50+ countries. 4. Documentation support: Complete export documentation provided.

Q1: What is the typical delivery time for a standard configuration foam water tender? A: The delivery time depends on the order quantity and customization level. For a standard configuration, it's typically around 30-45 days after order confirmation and receipt of down payment. Complex customization may require more time. Q2: Do you provide training for operators and maintenance personnel? A: Yes, we do. We can provide detailed operation and maintenance manuals (in English or required language). Upon request, we can arrange training sessions at the manufacturing site or provide video training materials. For overseas projects, on-site training and commissioning can be discussed. Q3: What are the warranty terms for the fire truck? A: The warranty period is typically 12 months from the date of shipment or arrival at the destination port, depending on our terms. The warranty covers defects in materials and workmanship under normal use. Specific terms will be detailed in the sales contract. Q4: Can the fire truck be customized for specific needs, like a different tank size or special equipment? A: Absolutely. Customization is one of our strengths. We can adjust the water/foam tank capacity and ratio, add specific equipment compartments, install different types of pumps or monitors, and accommodate other specific requirements based on customer needs. Q5: What about the supply of spare parts? A: We have a reliable supply chain for SHACMAN chassis parts. For the firefighting system components, we work with OEM to ensure genuine spare part availability. We also offer support in identifying local parts suppliers where possible. Q6: Which payment terms can you accept? A: Normally we can work on T/T term or L/C term, VISA, Paypal. (1) On T/T term, 30% down payment is required in advance, and 70% balance shall be settled before shipment, or against the copy of original B/L for long-term cooperating client. (2) On L/C term, a 100% irrevocable /C without "soit clauses" from an international recognized bank can be accepted. Please seek the advice from the individual sales manager whom you work with.

1. What is the primary mission and purpose? (1) Urban fire station: Responsible for general firefighting in the jurisdiction, requires a main water tender or pumper. (2) Industrial area/chemical plant: May require a foam fire truck, powder fire truck, or chemical accident rescue vehicle for oil and chemical fires. (3) Community/township: May require small or medium-sized fire trucks for navigating narrow roads. (4) Airport: Must procure specialized Aircraft Rescue and Fire Fighting (ARFF) vehicles. (5) Wildland firefighting: Requires forest fire trucks with strong off-road capability and large water tanks. Is the main task firefighting or rescue? Is an integrated rescue fire truck with functions like breaking, lighting, and smoke extraction needed?

A. About the Chassis 1. What's the chassis brand, model, and drive configuration?

1. Water Pump (1) Water pump model and brand? (e.g., Rosenbauer, Ziegler, or well-known domestic brands) (2) What is the rated flow and pressure? (e.g., 60L/s @1.0MPa) Flow determines water output volume, pressure determines range and height. (3) Does it meet the priming time requirement? (Usually≤35s at a 7m suction lift).
