SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
Specifications
Brand Name :
SHACMAN
Model Number :
SHACMAN H3000 Truck-mounted crane
Place of Origin :
SHAANXI,XIAN
MOQ :
1
Price :
Negotiable
Delivery Time :
35-55days
Description


Parameters

英文属性名称 英文属性值
Brand SHACMAN
Model H3000
Driving Form 6×4
Version Reinforced Version
Vehicle Model No. SX5288JSO MU584
Engine Model WP12.400E50
Horsepower 400HP
Emission Standard Euro V
Transmission Model 12JSD200T-B
Rear Axle Speed Ratio 4.266
Chassis Size 866×308mm (8+5+8)
Wheelbase 5775+1400mm
Rear Overhang 2900mm
Cab Type Standard Low Roof Cab
Front Axle HD 7.5T Disc/Drum Brake Front Axle
Suspension Multi-leaf spring suspension (4 main plates + 4 U-bolts, front & rear)
Fuel Tank 400L Aluminum Alloy Fuel Tank
Tire Specification 315/80R22.5 domestic tubeless mixed pattern tires
Cargo Box Size 8000×2450×600mm
Gross Vehicle Weight ≤50T
Application Construction Lifting, Material Handling, Heavy Transport
Working Road Condition Highways & Rough Construction Sites
Base Configuration H3000 standard low roof cab without deflector, Air suspension main seat, Lever-type rearview mirror, Electric A/C, Electric window lifter, Manual tilting, Metal bumper with light guard, 3-step boarding ladder, Central lock, Standard steering wheel, Vertical air filter, Standard exhaust, Imported WABCO 4-channel ABS, Left front tow hook & rear traction seat, Radiator protection grille, Taillight protection grille, Windproof oil pan protection grille, 180Ah maintenance-free battery
One Country One Version Configuration Four-point hydraulic suspension, Left & right curtains, No sunroof, No rear cab window, No sleeper curtain, Anti-splash fenders, Seat belt reminder function, High-brightness warning light on cab roof, 2 warning triangles, Engine with water cooling system, Iron air tank, Front under protection, Reverse buzzer, Jacksel compressor, Central spare tire rack, 32T jack, 8kg fire extinguisher, Steel grease fittings, Sun visor, Daytime running lights, LED taillights, 120km/h overspeed alarm, Spare power interface, Deluxe truck toolbox, Air gun interface in cab, Zoomlion remote gateway, Reserved port for driving recorder, Reserved port for side marker lights, Digital signal radio, Door sill guard, Swing-arm remote throttle controller, Arabic-English bilingual nameplates
Optional Configuration Electric tilting, 315/80R22.5 domestic tubeless tires (steer new, drive retreaded), HD 7.5T drum brake front axle, HD 9.5T drum brake front axle, Remove cab roof warning light



SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle

SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle

SHACMAN H3000 6x4 400HP Truck-Mounted Crane with 16T Rear Axle
