SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires
SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires
SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires
SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires
SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires
SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires
SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires
SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires
Specifications
Brand Name :
SHACMAN
Model Number :
F3000
Certification :
ISO 9001/CCC
Place of Origin :
Shaanxi,Xian
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T,L/C
Supply Ability :
1000 units/month
Delivery Time :
45 working days
Packaging Details :
Nude pack, with wax before shipment.
Modle :
SX3318DV366
Engine :
WP12.430E50-WEICHAI
Transmission :
12JSD200T-B+QH50-FAST
Axle :
9.5T /2*16 T Double-stage, speed ratio-4.769
Wheel base :
1800+3575+1400 mm
Tire :
12.00R20 (10+1)
Fuel tank :
300L
Clutch :
φ430 Diaphragm spring clutch
Air inlet :
Ordinary air filter
Chassis :
850×300（8+7）
Suspension :
Front /rear Multi-layer plate spring 4 main plates + 4 U-shaped bolts
Cabin :
Medium-length flat top
Color :
Neon Red/Green Mountain Green/Star and Moon Blue/Aurora White/Klein Blue/Brandy
Description
SHACMAN F3000 Dump Truck 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper
Product Overview

The SHACMAN F3000 Dump Truck is a robust 8x4 tipper designed for heavy-duty material transportation. Featuring a 430HP EuroV compliant engine and domestic front lift mechanism, this truck combines power with environmental responsibility.

Key Specifications
Model: SX3318DV366
Drive Type: 8x4
Engine: WEICHAI WP12.430E50
Power: 316kw / 430Hp
Transmission: FAST 12JSD200T-B+QH50
Emission Standard: Euro V
Technical Specifications
Category Specification
Weight Gross Vehicle Weight ≤70
Dimensions Wheelbase: 1800+3575+1400 mm
Performance Maximum speed: 40～55/75 km/h
Ground clearance: >314 mm
Engine WEICHAI WP12.430E50
316kw / 430Hp
2050 N*M maximum torque
11.596 L displacement
Drivetrain FAST 12JSD200T-B+QH50 gearbox
φ430 Diaphragm spring clutch
Braking System Drum brakes
Double circuit air brake (Service)
Rear wheel spring brake (Park)
WEVB engine exhaust brake (Auxiliary)
Chassis & Suspension Parallel trapezoidal frame (850×300(8+7) mm)
Multi-layered leaf springs (Front: 4 Main+4 U Bolts, Rear: 4 Main+4 U Bolts)
Axles HANDE 9.5T front axle (MAN technology)
16T MAN Double Reduction Drive rear axle (4.769 ratio)
Other Components 12.00R20 tires
300L Aluminum fuel tank
24V electrical system with 165Ah battery
Cab Features F3000 Medium-length flat cab
Hydraulic main seat
Four-point hydraulic suspension
Electronically controlled automatic AC
Electric windows
Key Advantages
  • Robust Construction: Heavy-duty chassis and suspension system provide excellent load-bearing capacity and stability for safe transportation on rough terrain.
  • Eco-Friendly: Complies with strict Euro V emission standards, significantly reducing nitrogen oxides (NOx) and particulate matter (PM) emissions.
Company Information
About Us

Based in Shaanxi, China since 2015, we specialize in manufacturing and exporting heavy-duty trucks to global markets including Africa (70%), Southeast Asia (10%), and the Americas (14%). Our team of 11-50 professionals ensures quality products and service.

Quality Assurance

We implement strict quality control measures including pre-production sampling to validate design, functionality, and quality before mass production.

Product Range

Our product portfolio includes Dump trucks, Track trucks, Lorry trucks, Van trucks, and Mixer trucks.

Services Offered

We accept various delivery terms (FOB, CFR, CIF, EXW, CIP, DDU) and payment methods (T/T, L/C, D/P D/A) in multiple currencies (USD, EUR, CNY). Our team communicates in English and French.
