Product Description

This is a very practical packing machine on the market at present,with reasonable structural design to ensure packaging efficiency and product quality.The compact body size save space and is suitable for a variety of production enviroments.at the same time,the machine is easy to operate,easy to maintain,so that you can easy to control.

Fully Automatic and Semi Automatic are optional

When the packaging machine enters the automatic operation state, the weighing control system opens the feeding door to start
feeding.
The feeding device is a fast and slow feeding mode.

When the material weight reaches the set value of fast feeding,
the fast feeding is stopped and the slow feeding is maintained.
When the material weight reaches the set value, the feeding door is closed to complete the dynamic weighing process.

At this time, the system detects whether the bag clamping device is in When the bag has been clamped, the system will send a
control signal to open the unloading door of the weighing bucket, and the material will enter the bag, then unloading door of the
weighing bucket will be closed automatically;

after the material is unloaded, the bag clamping device will be released and the bag will fall down automatically; after the bag
is dropped, the bag will be sewn and transported to the next processis way, it operates automatically.

How does Packing Machine Work:Giving the bag (loading the bag) → automatically clamps the bag→ material is automatically
quantitatively weighed and filled into bags→ automatic bag release /bag holding/bag transfer→ automatic label feeding /folding /or
heat sealing/or sewing→ entering the next process

Advantage: -Wide packing range, high precision, it can match well with conveyor and sewing machine. -Products using imported
sensor, pneumatic actuator, easy maintenance and non-pollution. -The main material body is carbon steel, with painted plastic. And
material contact part can be 304 Stainless Steel or 316 Stainless Steel Semi-automatic machine also can be customized it can be
customized according to the client's requirementsneeds
Details Images
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Specification
Material
SS304 3mm Contact parts
Gross Weight
5000kg
2Packing Capacity
600-800 bags/h
Weighing Range
25-50kg or Customized
Quantify Precision
±0.2%
Power
5kw
Power Supply
AC 220V/380V 50 HZ 1P/3P Customized
Air Source
0.4~0.6MPa 0.36m³/min
Application Materials
Applicable for packing granular or particle materials such as chemistry, fertilizer, grain, rice, sand, wood pellets, animal feed,urea, phosphate, PP, PE granules, construction materials
Application Materials
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Packing & Delivery
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
Why Choose Us
Fully Automatic FFS Packing Machine Grain Barley Rice Quartz Sand Synthetic 20KG 25KG with Bag Making Packaging Machines
FAQ
Q1: Are you factory or trading company? A1: We are the factory, we doing this line for more than 10 years. Q2: How to choose suitable packaging machine? A2: Need to provide your material pictures and requirements, such as packaging speed, packaging weight, bag type and bag size. Q3: How to ensure the quality of the machine? A3: We usually delivery the machine after successful inspection in our factory. We have our own quality control department,beforethe delivery we have to running the machine for three days without problem. You can send us your materials and we will make video as long as you want. Or you can arrange a third-party inspection agency. Q4: How to install the equipment? A4: We will provide manuals and detailed videos to help customer install machine. If necessary, we will send technicians to the customer's factory to assist, and the customer only needs to pay. Q5: What's your payment way? A5: T/T by our bank account directly, or by Alibaba trade assurance service, or by West Union, or L/C.
