Specifications
Brand Name :
Lenovo
Model Number :
Lenovo ThinkSystem SR630 V4 1U Rack Server
Place of Origin :
China
MOQ :
1/set
Payment Terms :
T/T
Supply Ability :
50pcs per week
Delivery Time :
2-3 work days
Processors :
Up to 2x Intel® Xeon® 6 processors, up to 288 cores
Memory :
Supports up to 32x TruDDR5 RDIMMs, MCRDIMMs
GPUs :
Up to 3x single-width 75W GPUs
Power Supply :
Dual Redundant AC & DC; Platinum & Titanium; 800W, 1300W, 2000W, and 1100W -48V DC Platinum
Expansion Slots :
Up to 3x PCIe 5.0 slots 2x OCP 3.0 slots
SystemsManagement :
XClarity Controller v3
Drive Bays :
Up to 12x 2.5” or 16x EDSFF E3.S
Description

The ThinkSystem SR630 V4 server is powered by dual Intel® Xeon® 6 processors with a new class of Performance-cores (P-cores) and provides up to 172 cores and support MRDIMMs for ultra performance.

Compared to the previous generation, the SR630 V4 doubles the number of cores per rack and increasing performance for high density and scale out workload in customer segments like cloud service providers (CSP) and telecommunication service and financial services over the previous generations.

The increase in cores per rack maximizes the number of workloads managed per rack. With the SR630 V4 a customer can consolidate workloads, reduce their data center footprint, and easily plan for future expansion.

Processor Up to 2x Intel® Xeon® 6 processors, up to 288 cores

Drive Bays

Up to 12x 2.5” or 16x EDSFF E3.S

Front: Up to 10x 2.5” / 16x EDSFF E3.S (16x1T/8x2T), hot-swap

Rear: 2x 2.5”, hot-swap

2x M.2 boot drives, optional hot-swap

Direct NVMe, VROC/VMD (R0,1,5,10)
Memory Supports up to 32x TruDDR5 RDIMMs, MCRDIMMs
Expansion Slots

Up to 3x PCIe 5.0 slots

2x OCP 3.0 slots

1x cabled internal HBA/RAID adapter
GPUs Up to 3x single-width 75W GPUs
Power

Dual Redundant AC & DC; Platinum & Titanium; 800W, 1300W, 2000W, and 1100W -48V DC Platinum

Supports Industry standard CRPS form factor supplies
SystemsManagement XClarity Controller v3
Cooling Solution

Lenovo Neptune® Core for processors & memories

Neptune® Air technology for processors
